Database Security Best Practices and Solutions

Securing your PostgreSQL database is crucial for protecting sensitive data and maintaining the integrity of your system. The Center for…

Database Security Best Practices and Solutions

Securing your PostgreSQL database is crucial for protecting sensitive data and maintaining the integrity of your system. The Center for Internet Security (CIS) provides benchmarks to guide database administrators in securing their PostgreSQL instances. This article will outline the key CIS recommendations and how to set them correctly.

1. Installation and Patches

1.1 Ensure Packages Are Obtained from Authorized Repositories

  • 1.1.1 PostgreSQL Packages Installed (Manual): Ensure PostgreSQL packages are installed correctly.
# Check Installed PostgreSQL Packages for On Red Hat Based Systems
rpm -qa | grep postgresql

# You can check your rpm your outputs
postgresql13-libs-13.13-1PGDG.rhel9.x86_64
postgresql13-13.13-1PGDG.rhel9.x86_64
postgresql13-server-13.13-1PGDG.rhel9.x86_64
postgresql13-contrib-13.13-1PGDG.rhel9.x86_64
postgresql13-devel-13.13-1PGDG.rhel9.x86_64

/*
This command lists all RPM packages with "postgresql" in their names.
You should see entries like above this;
postgresql-server
postgresql-libs
and postgresql-contrib.
*/
  • 1.1.2 Ensure Packages Are Obtained from PGDG: Verify that packages are sourced from the PostgreSQL Global Development Group (PGDG) repository.

1.2 Ensure Systemd Service Files Are Enabled

  • Enable and configure systemd service files to manage PostgreSQL services.
# Check direcktly postgresql service if you do not use service that run postgresql
systemctl status postgresql-13.service

# In case using other service such us patroni, you can check other service
systemctl status patroni.service

# Do not forget patroni default preset is disable
# so you have to enable your service due to the fact that machine boot
# Service running and active
● patroni.service - Runners to orchestrate a high-availability PostgreSQL
     Loaded: loaded (/usr/lib/systemd/system/patroni.service; enabled; preset: disabled)
     Active: active (running) since Wed 2024-04-24 14:55:46 +03; 1 month 5 days ago
   Main PID: 1151 (patroni)
      Tasks: 24 (limit: 203328)
     Memory: 16.1G
        CPU: 2d 11h 58min 56.969s
     CGroup: /system.slice/patroni.service

1.3 Ensure Data Cluster Initialized Successfully

  • 1.3.1 Check Initialization of the PGDATA: Verify that the data directory (PGDATA) is initialized properly.
#directory list command for On Red Hat Based Systems.

sudo ls -l /pg_data/data/ #you can chechk your directory with sql "SHOW data_directory;"


# You can see like this output
-rw-------  1 postgres postgres   179 Mar 25 23:03 backup_label.old
drwx------ 63 postgres postgres  4096 May 30 09:24 base
-rw-------  1 postgres postgres    52 May 30 00:00 current_logfiles
drwx------  2 postgres postgres  4096 May 30 09:31 global
drwx------  2 postgres postgres    32 Feb  7 15:30 log
-rw-------  1 postgres postgres  1896 May 27 15:53 patroni.dynamic.json
drwx------  2 postgres postgres     6 Feb  7 15:30 pg_commit_ts
drwx------  2 postgres postgres     6 Feb  7 15:30 pg_dynshmem
-rw-------  1 postgres postgres  5996 May  6 14:51 pg_hba.conf
-rw-------  1 postgres postgres  5996 May  7 11:33 pg_hba.conf.backup
-rw-------  1 postgres postgres  1636 Mar 25 23:01 pg_ident.conf
-rw-------  1 postgres postgres  1636 May  7 11:33 pg_ident.conf.backup
drwx------  4 postgres postgres    84 May 30 09:59 pg_logical
drwx------  4 postgres postgres    48 Feb  7 15:30 pg_multixact
drwx------  2 postgres postgres     6 Feb  7 15:30 pg_notify
drwx------  4 postgres postgres    50 May  8 13:43 pg_replslot
drwx------  2 postgres postgres     6 Feb 12 14:42 pg_serial
drwx------  2 postgres postgres     6 Feb 12 14:33 pg_snapshots
drwx------  2 postgres postgres     6 May  7 11:33 pg_stat
drwx------  2 postgres postgres  4096 May 30 10:20 pg_stat_tmp
drwx------  2 postgres postgres    26 May 25 11:50 pg_subtrans
drwx------  2 postgres postgres     6 Feb 27 15:42 pg_tblspc
drwx------  2 postgres postgres     6 Feb 12 14:41 pg_twophase
-rw-------  1 postgres postgres     3 Feb  7 15:30 PG_VERSION
lrwxrwxrwx  1 postgres postgres     7 Feb  7 15:30 pg_wal -> /pg_wal
drwx------  2 postgres postgres    26 Feb 12 14:37 pg_xact
-rw-------  1 postgres postgres    88 Mar 25 23:03 postgresql.auto.conf
-rw-------  1 postgres postgres 28098 Mar 25 23:03 postgresql.base.conf
-rw-------  1 postgres postgres 28098 May  7 11:33 postgresql.base.conf.backup
-rw-r--r--  1 postgres postgres  2475 May 27 15:53 postgresql.conf
-rw-r--r--  1 postgres postgres  2475 May  7 11:33 postgresql.conf.backup
-rw-------  1 postgres postgres   433 May  7 11:33 postmaster.opts
-rw-------  1 postgres postgres    99 May  8 13:43 postmaster.pid
  • 1.3.2 Check Version in PGDATA: Ensure the PostgreSQL version in the data directory matches the installed version.
cat /pg_data/data/PG_VERSION
# Output
13

psql --version
# Output
psql (PostgreSQL) 13.13
  • 1.3.3 Ensure Data Cluster Has Checksum Enabled: Enable checksums for data integrity.
#Please do not forget to use postgres user
pg_controldata /pg_data/data/ | grep "Data page checksum version"

#Output

Data page checksum version:           1

# If it says 1, checksums are enabled. If it says 0, checksums are not enabled.
  • 1.3.4 Ensure WALs and Temporary Files Are Not on the Same Partition as the PGDATA: Separate write-ahead logs (WALs) and temporary files from the data directory.

lvs #Logical volume size command
# Output
  LV         VG     Attr       LSize    Pool Origin Data%  Meta%  Move Log Cpy%Sync Convert
  pg_data_lv datavg -wi-ao----   <2.25t
  pg_log_lv  datavg -wi-ao----  300.00g
  pg_temp_lv datavg -wi-ao----  300.00g
  pg_wal_lv  datavg -wi-ao---- <172.00g
  homelv     rootvg -wi-ao----   10.00g
  rootlv     rootvg -wi-ao----   20.00g
  swaplv     rootvg -wi-ao----   20.00g
  varlv      rootvg -wi-ao----   10.00g


pvs #Physical volume size command
# Output
  PV         VG     Fmt  Attr PSize   PFree
  /dev/sda2  rootvg lvm2 a--  <99.00g <39.00g
  /dev/sdb1  datavg lvm2 a--   <3.00t      0


lsblk # list block devices
# Output
NAME                  MAJ:MIN RM  SIZE RO TYPE MOUNTPOINTS
sda                     8:0    0  100G  0 disk
├─sda1                  8:1    0    1G  0 part /boot
└─sda2                  8:2    0   99G  0 part
  ├─rootvg-rootlv     253:0    0   20G  0 lvm  /
  ├─rootvg-swaplv     253:1    0   20G  0 lvm  [SWAP]
  ├─rootvg-varlv      253:6    0   10G  0 lvm  /var
  └─rootvg-homelv     253:7    0   10G  0 lvm  /home
sdb                     8:16   0    3T  0 disk
└─sdb1                  8:17   0    3T  0 part
  ├─datavg-pg_wal_lv  253:2    0  172G  0 lvm  /pg_wal
  ├─datavg-pg_log_lv  253:3    0  300G  0 lvm  /pg_log
  ├─datavg-pg_temp_lv 253:4    0  300G  0 lvm  /pg_temp
  └─datavg-pg_data_lv 253:5    0  2.2T  0 lvm  /pg_data
sr0                    11:0    1 1024M  0 rom


#This example did not pass our exam due to logical volume partitioning, but not the physical one
  • 1.3.5 Ensure the PGDATA Partition Is Encrypted (Manual): Encrypt the partition containing the data directory.
lsblk -o NAME,FSTYPE,FSVER,LABEL,UUID,FSAVAIL,FSUSE%,MOUNTPOINT

NAME                  FSTYPE      FSVER    LABEL UUID                                   FSAVAIL FSUSE% MOUNTPOINT
sda
├─sda1                xfs                        3cd2b87c-ddbe-49b1-a770-80001f33c95d    674.2M    34% /boot
└─sda2                LVM2_member LVM2 001       dptPYc-9Hxh-GD5C-Jaa1-1zhI-E3L4-HV0rHn
  ├─rootvg-rootlv     xfs                        fdd0848b-a7fe-4754-a726-c86253f621ef     10.5G    47% /
  ├─rootvg-swaplv     swap        1              18b5352c-7a6a-4d5b-b9ac-2ad02ab7a489                  [SWAP]
  ├─rootvg-varlv      xfs                        03ea089a-1a53-48b9-b9cc-042a548c47b4      6.9G    31% /var
  └─rootvg-homelv     xfs                        dba1b3ee-c531-4701-a793-c5591569a229      9.9G     1% /home
sdb
└─sdb1                LVM2_member LVM2 001       I2xKSO-853B-eu6f-HMIc-lsbT-f5O1-eRjrma
  ├─datavg-pg_wal_lv  xfs                        03ce8167-0476-4581-9e95-633e3b63ba03     63.7G    63% /pg_wal
  ├─datavg-pg_log_lv  xfs                        e48f8a8e-75ba-41f1-93a8-1978e841a1af    296.3G     1% /pg_log
  ├─datavg-pg_temp_lv xfs                        74438755-9e98-4bfb-8baf-e837d196c545    297.7G     1% /pg_temp
  └─datavg-pg_data_lv xfs                        d8bfaded-6e81-48b2-a32a-2eb6e4f9dadb      1.8T    20% /pg_data
sr0


"""
Check the "FSTYPE" column to see the file system type of the partition.
If it's encrypted
it will likely be a type such as "crypto_LUKS" or "crypt"
instead of a specific file system like "ext4" or "xfs".
"""
#This example did not pass our exam
#We may need to encrypt it manually using tools like LUKS
#(Linux Unified Key Setup) or other encryption mechanisms supported by your Linux distribution.


"""
To manually encrypt a partition using LUKS (Linux Unified Key Setup)
"""

sudo dnf install cryptsetup
sudo umount /mnt/data
sudo cryptsetup luksFormat /dev/sdXn
#Open the Encrypted Partition
sudo cryptsetup open /dev/sdXn cryptdata
#Create a File System on the Encrypted Partition
sudo mkfs.ext4 /dev/mapper/cryptdata
sudo mkdir /mnt/cryptdata
#Mount the Encrypted Partition
sudo mount /dev/mapper/cryptdata /mnt/cryptdata
#Update /etc/fstab and /etc/crypttab
sudo nano /etc/crypttab
#Add a line like this:
cryptdata /dev/sdXn none luks
sudo nano /etc/fstab
#Edit /etc/fstab to include the mount point:
sudo nano /etc/fstab
# Add a line like this:
/dev/mapper/cryptdata /mnt/cryptdata ext4 defaults 0 2
sudo systemctl start cryptsetup.target
sudo mount -a

1.4 Ensure PostgreSQL Versions Are Up-to-Date

  • Regularly update PostgreSQL to the latest stable version to mitigate vulnerabilities.
if you do not have internet connection you can skip this step

1.5 Ensure Unused PostgreSQL Extensions Are Removed

  • Remove any unnecessary extensions to reduce the attack surface.
postgres=# \dx
                                            List of installed extensions
        Name        | Version |   Schema   |                              Description
--------------------+---------+------------+------------------------------------------------------------------------
 btree_gist         | 1.5     | public     | support for indexing common datatypes in GiST
 dblink             | 1.2     | public     | connect to other PostgreSQL databases from within a database
 pg_profile         | 4.3     | profile    | PostgreSQL load profile repository and report builder
 pg_qualstats       | 2.1.0   | public     | An extension collecting statistics about quals
 pg_stat_kcache     | 2.2.2   | public     | Kernel statistics gathering
 pg_stat_statements | 1.8     | public     | track planning and execution statistics of all SQL statements executed
 pg_wait_sampling   | 1.1     | public     | sampling based statistics of wait events
 plpgsql            | 1.0     | pg_catalog | PL/pgSQL procedural language
(8 rows)

postgres=# SELECT * FROM pg_extension;
  oid   |      extname       | extowner | extnamespace | extrelocatable | extversion | extconfig | extcondition
--------+--------------------+----------+--------------+----------------+------------+-----------+--------------
  13486 | plpgsql            |       10 |           11 | f              | 1.0        |           |
 707724 | dblink             |       10 |         2200 | t              | 1.2        |           |
 707770 | pg_profile         |       10 |       707723 | f              | 4.3        |           |
  17717 | btree_gist         |       10 |         2200 | t              | 1.5        |           |
  18340 | pg_stat_statements |       10 |         2200 | t              | 1.8        |           |
  18354 | pg_stat_kcache     |       10 |         2200 | t              | 2.2.2      |           |
  18367 | pg_qualstats       |       10 |         2200 | f              | 2.1.0      |           |
  18407 | pg_wait_sampling   |       10 |         2200 | t              | 1.1        |           |
(8 rows)

#you can check your extension two method. If you do not use anymore please drop your extension.

1.6 Ensure Tablespace Location Is Not Inside the PGDATA

  • Configure tablespaces to reside outside the main data directory.
/*
Tablespaces can be used mainly for two purposes:
(1) “extend” the capacity of the disk where the data directory was created by adding data to a separate disk device,
(2) to improve the performance of some operations and leverage the capacities of different storage devices
*/

\db+ /*Chech your tablespaces*/


CREATE TABLESPACE newspace LOCATION ‘/ssd1/postgres/newspace’;

CREATE DATABASE cbsm TABLESPACE newspace;

2. Directory and File Permissions

2.1 Ensure the File Permissions Mask Is Correct

  • Set the correct file permissions mask to prevent unauthorized access.
/*
The umask must be 0077 or more restrictive for the postgres user.
Currently it is set to 0022.
*/

su - postgres
unmask # check your defalt umask
#output
0022
echo 'umask 077' >> .bash_profile
source .bash_profile
umask
#output
0077


/*

        Common umask Settings
umask User Access Group Access Other
0000  all         all          all
0002  all         all          read, execute
0007  all         all          none
0022  all         read,execute read, execute
0027  all         read,execute none
0077  all         none         none

*/

2.2 Check Permissions of PGDATA

  • Ensure the data directory permissions are set to restrict access appropriately. The data cluster Unix permissions must be 0700.
ls -ld /pg_data/data/

#output
drwx------ 19 postgres postgres 4096 May 30 00:00 /pg_data/data/


stat -c "%a" /pg_data/data/

#output
700

2.3 List Content of PGDATA to Check Unwanted Files and Symlinks

  • Manually review the contents of the data directory for any unwanted files or symbolic links.
# The content of the PGDATA must be generated by PostgreSQL itself except custom configuration files.
ls -ln /pg_data/data/

#Output
-rw-------  1 26 26   179 Mar 25 23:03 backup_label.old
drwx------ 63 26 26  4096 May 30 09:24 base
-rw-------  1 26 26    52 May 30 00:00 current_logfiles
drwx------  2 26 26  4096 May 30 11:31 global
drwx------  2 26 26    32 Feb  7 15:30 log
-rw-------  1 26 26  1896 May 27 15:53 patroni.dynamic.json
drwx------  2 26 26     6 Feb  7 15:30 pg_commit_ts
drwx------  2 26 26     6 Feb  7 15:30 pg_dynshmem
-rw-------  1 26 26  5996 May  6 14:51 pg_hba.conf
-rw-------  1 26 26  5996 May  7 11:33 pg_hba.conf.backup
-rw-------  1 26 26  1636 Mar 25 23:01 pg_ident.conf
-rw-------  1 26 26  1636 May  7 11:33 pg_ident.conf.backup
drwx------  4 26 26    84 May 30 14:58 pg_logical
drwx------  4 26 26    48 Feb  7 15:30 pg_multixact
drwx------  2 26 26     6 Feb  7 15:30 pg_notify
drwx------  4 26 26    50 May  8 13:43 pg_replslot
drwx------  2 26 26     6 Feb 12 14:42 pg_serial
drwx------  2 26 26     6 Feb 12 14:33 pg_snapshots
drwx------  2 26 26     6 May  7 11:33 pg_stat
drwx------  2 26 26  4096 May 30 15:14 pg_stat_tmp
drwx------  2 26 26    26 May 25 11:50 pg_subtrans
drwx------  2 26 26     6 Feb 27 15:42 pg_tblspc
drwx------  2 26 26     6 Feb 12 14:41 pg_twophase
-rw-------  1 26 26     3 Feb  7 15:30 PG_VERSION
lrwxrwxrwx  1 26 26     7 Feb  7 15:30 pg_wal -> /pg_wal
drwx------  2 26 26    26 Feb 12 14:37 pg_xact
-rw-------  1 26 26    88 Mar 25 23:03 postgresql.auto.conf
-rw-------  1 26 26 28098 Mar 25 23:03 postgresql.base.conf
-rw-------  1 26 26 28098 May  7 11:33 postgresql.base.conf.backup
-rw-r--r--  1 26 26  2475 May 27 15:53 postgresql.conf
-rw-r--r--  1 26 26  2475 May  7 11:33 postgresql.conf.backup
-rw-------  1 26 26   433 May  7 11:33 postmaster.opts
-rw-------  1 26 26    99 May  8 13:43 postmaster.pid

2.4 Check Permissions of pg_hba.conf

  • Verify that the pg_hba.conf file permissions restrict access to authorized users only. The pg_hba.conf UNIX permission must be 0640 or 0600, especially when it is stored outside the PGDATA

# The pg_hba.conf UNIX permission must be 0640 or 0600, especially when it is stored outside the PGDATA
ls -ld /pg_data/data/pg_hba.conf
#output
-rw------- 1 postgres postgres 5996 May  6 14:51 /pg_data/data/pg_hba.conf

stat -c "%a" /pg_data/data/pg_hba.conf
#output
600

2.5 Check Permissions on Unix Socket

  • Ensure the Unix socket permissions are correctly set to secure local connections. The default permissions are 0777, meaning anyone can connect. Reasonable alternatives are 0770 (only user and group, see also unix_socket_group) and 0700 (only user).

psql -c 'SHOW unix_socket_directories;'
#output
unix_socket_directories
---------------------------
 /var/run/postgresql, /tmp

ls -ld /var/run/postgresql
#output
drwxr-xr-x 2 postgres postgres 80 May  7 11:33 /var/run/postgresql

stat -c "%a" /var/run/postgresql
#output
755

2.6 Disable PostgreSQL Command History

  • On Linux/UNIX, the PostgreSQL client logs most interactive statements to a history file. The default PostgreSQL history file is named .psql_history in the user’s home directory.
#Remove .psql_history if it exists.

rm -f ~<user>/.psql_history || true

#Use either of the techniques below to prevent it from being created again:
#Set the HISTFILE variable to /dev/null in ~<user>/.psqlrc

cat << EOF >> ~<user>/.psqlrc
\set HISTFILE /dev/null
EOF

#Create ~<user>/.psql_history as a symbolic to /dev/null.

ln -s /dev/null $HOME/.psql_history

#Set the PSQL_HISTORY variable for all users:

sudo echo 'PSQL_HISTORY=/dev/null' >> /etc/environment

3. Logging and Auditing

3.1 PostgreSQL Logging

  • 3.1.1 Logging Rationale: Understand the importance of logging for monitoring and auditing. Having an audit trail is an important feature of any relational database system.
You want enough detail to describe when an event of interest has started
and stopped, what the event is/was, the event's cause, and what the event
did/is doing to the system. Ideally, the logged information is in a format
permitting further analysis giving us new perspectives and insight.
  • 3.1.2 Ensure the Log Destinations Are Set Correctly: Configure log destinations to capture all relevant logs. The log destinations should comply with your organization’s policies on logging. If all the expected log destinations are not set, this is a fail.
show log_destination;

 log_destination
-----------------
 stderr

/*
stderr log/postgresql.log
csvlog log/postgresql.csv
jsonlog log/postgresql.json  /*required version at least 15*/
*/

alter system set log_destination = 'csvlog';
/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.3 Ensure the Logging Collector Is Enabled: Enable the logging collector to manage log files. When enabling this parameter, a background process is started, and it captures all the messages sent to the standard error (stderr) and redirects them into log files. The default value for this parameter is off; however, it is highly recommended to set
    it to on.
show logging_collector;

 logging_collector
 - - - - - - - - - -
 off

alter system set logging_collector = 'on';
/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.4 Ensure the Log File Destination Directory Is Set Correctly: Specify an appropriate directory for log files. under high workloads, avoid causing an impact on the disk for the database operations by moving the log files to a different disk
show log_directory;

 log_directory
 - - - - - - - - - -
log

alter system set log_directory='/pg_log/log';
/* Reload configuretion file */
select pg_reload_conf();

/*
Please do not forget logical volume is not enough. Also, physcihal volume is required.
*/
  • 3.1.5 Ensure the Filename Pattern for Log Files Is Set Correctly (Manual): Set a clear and consistent pattern for log file names.
show log_filename;
 log_filename
-------------------
postgresql-%a.log

/* Change your file name */
alter system set log_filename='postgresql-%Y-%m-%d_%H%M%S.log';

/* Reload configuretion file */
select pg_reload_conf();


show log_filename;
          log_filename
--------------------------------
 postgresql-%Y-%m-%d_%H%M%S.log

  • 3.1.6 Ensure the Log File Permissions Are Set Correctly: Restrict access to log files to prevent tampering.
show log_file_mode;
 log_file_mode
 - - - - - - - -
 0600

/* if you have correct mode, please alter your mode. Default Value: 0600*/
alter system set log_file_mode = '0600';

/* Reload configuretion file */
select pg_reload_conf();

  • 3.1.7 Ensure ‘log_truncate_on_rotation’ Is Enabled: Enable log truncation on rotation to manage log file sizes.
show log_truncate_on_rotation;

log_truncate_on_rotation
--------------------------
on

/* Default Value:on */
alter system set log_truncate_on_rotation = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.8 Ensure the Maximum Log File Lifetime Is Set Correctly (Manual): Define a suitable log file lifetime. When the logging_collector is enabled, this parameter controls if the messages sent to an existing log file will be appended (off) or the file will be truncated/overwritten (on). As we saw before, this can be combined with the log_filename to control the number of files to store. For example, if the log_filename is configured as postgresql-%H.log, the log_rotation_age is on its default of 1440 minutes (1 day), and the log_truncate_on_rotation is on, then every hour, a new empty file will be created, and PostgreSQL will keep only 24 files. This is only related your company strategies.
 show log_rotation_age;
 log_rotation_age
------------------
 1d

/* Default Value: 1d (one day) */
alter system set log_rotation_age='1h';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.9 Ensure the Maximum Log File Size Is Set Correctly (Manual): Set an appropriate maximum size for log files. This parameter can be used when the logging_collector is enabled If the value has no units specified, it is calculated as kilobytes. The default value is 0MB, and setting it to 0 (zero) disables the size-based rotation.
show log_rotation_size;
 log_rotation_size
-------------------
 0


/* Default Value: 0 */
alter system set log_rotation_size = '1GB';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.10 Ensure the Correct Syslog Facility Is Selected : Configure the correct syslog facility for PostgreSQL logs.
show syslog_facility;
syslog_facility
-----------------
local0


/* Default Value: LOCAL0 */
alter system set syslog_facility = 'LOCAL1';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.11 Ensure Syslog Messages Are Not Suppressed: Allow all relevant syslog messages to be captured.
show syslog_sequence_numbers;

syslog_sequence_numbers
-------------------------
on

/* Default Value: on */
alter system set syslog_sequence_numbers = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.12 Ensure Syslog Messages Are Not Lost Due to Size: Prevent loss of syslog messages by configuring appropriate size limits.
show syslog_split_messages;

syslog_split_messages
-----------------------
on

/* Default Value: on */
alter system set syslog_split_messages = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.13 Ensure the Program Name for PostgreSQL Syslog Messages Is Correct (Manual): Set the correct program name for syslog messages. If this is not set correctly, it may be difficult or impossible to distinguish PostgreSQL messages from other messages in Syslog logs.
show syslog_ident;

 syslog_ident
--------------
 postgres

/* Default Value: postgres */
alter system set syslog_ident = 'proddb';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.14 Ensure the Correct Messages Are Written to the Server Log: Ensure all necessary log messages are captured. If this is not set to the correct value, too many or too few messages may be written to the server log.
/*
• DEBUG5 <-- exceedingly chatty
• DEBUG4
• DEBUG3
• DEBUG2
• DEBUG1
• INFO
• NOTICE
• WARNING <-- default
• ERROR
• LOG
• FATAL
• PANIC <-- practically muteshow syslog_ident;

WARNING is considered the best practice unless indicated otherwise by your
organization's logging policy.
*/

show log_min_messages;

log_min_messages
------------------
warning

/* Default Value: warning */
alter system set log_min_messages = 'warning';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.15 Ensure the Correct SQL Statements Generating Errors Are Recorded: Log SQL statements that cause errors.
show log_min_error_statement;

log_min_error_statement
-------------------------
error

/* Default Value: error */
alter system set log_min_error_statement = 'error';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.16 Ensure ‘debug_print_parse’ Is Disabled: Disable debug printing of parse trees.
show debug_print_parse;

debug_print_parse
-------------------
off

/* Default Value: off */
alter system set debug_print_parse='off';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.17 Ensure ‘debug_print_rewritten’ Is Disabled: Disable debug printing of rewritten queries.
show debug_print_rewritten;

debug_print_rewritten
-----------------------
off

/* Default Value: off */
alter system set debug_print_rewritten = 'off';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.18 Ensure ‘debug_print_plan’ Is Disabled: Disable debug printing of execution plans.
show debug_print_plan;

debug_print_plan
------------------
off

/* Default Value: off */
alter system set debug_print_plan = 'off';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.19 Ensure ‘debug_pretty_print’ Is Enabled: Enable pretty printing for easier debugging.
show debug_pretty_print;

debug_pretty_print
--------------------
on

/* Default Value: on */
alter system set debug_pretty_print = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.20 Ensure ‘log_connections’ Is Enabled: Log connection attempts.
show log_connections;

log_connections
-----------------
on

/* Default Value: on */
alter system set log_connections = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.21 Ensure ‘log_disconnections’ Is Enabled: Log disconnections.
show log_disconnections;

log_disconnections
--------------------
on

/* Default Value: on */
alter system set log_disconnections = 'on';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.22 Ensure ‘log_error_verbosity’ Is Set Correctly: Configure the verbosity level of error logs. The log_error_verbosity setting specifies the verbosity (amount of detail) of logged messages. with each containing the fields of the level above it as well as additional fields.
    TERSE excludes the logging of DETAIL, HINT, QUERY, and CONTEXT error information. VERBOSE output includes the SQLSTATE, error code, and the source code file name, function name, and line number that generated the error. The appropriate value should be set based on your organization’s logging policy.
Valid values are:
• TERSE
• DEFAULT
• VERBOSE

show log_error_verbosity;

 log_error_verbosity
---------------------
 default

/* Default Value: default */
alter system set log_error_verbosity = 'verbose';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.23 Ensure ‘log_hostname’ Is Set Correctly: Log hostnames in addition to IP addresses.
show log_hostname;

log_hostname
--------------
off

/* Default Value: off */
 alter system set log_hostname='off';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.24 Ensure ‘log_line_prefix’ Is Set Correctly: Define a clear and informative log line prefix.

%a = application name
%u = user name
%d = database name
%r = remote host and port
%h = remote host
%b = backend type
%p = process ID
%P = process ID of parallel group leader
%t = timestamp without milliseconds
%m = timestamp with milliseconds
%n = timestamp with milliseconds (as a Unix epoch)
%Q = query ID (0 if none or not computed)
%i = command tag
%e = SQL state
%c = session ID
%l = session line number
%s = session start timestamp
%v = virtual transaction ID
%x = transaction ID (0 if none)
%q = stop here in non-session processes
%% = '%'

show log_line_prefix;

 log_line_prefix
-----------------
 %m [%p]

/* Default Value: %m [%p]*/
alter system set log_line_prefix = '%m [%p]: [%l-1] db=%d,user=%u,app=%a,client=%h ';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.25 Ensure ‘log_statement’ Is Set Correctly: Configure which SQL statements to log. It is recommended this be set to ddl unless otherwise directed by your organization’s logging policy. PREPARE, EXECUTE, and EXPLAIN ANALYZE statements are also logged if their contained command is of an appropriate type.) For clients using extended query protocol, logging occurs when an Execute message is received, and values of the Bind parameters are included (with any embedded singlequote marks doubled).
/*
The log_statement setting specifies the types of SQL statements that are logged.
Valid values are:
• none (off)
• ddl
• mod
• all (all statements)

ddl logs all data definition statements:
• CREATE
• ALTER
• DROP

mod logs all ddl statements, plus data-modifying statements:
• INSERT
• UPDATE
• DELETE
• TRUNCATE
• COPY FROM
*/

show log_statement;

 log_statement
---------------
 none

/* Default Value: none */
alter system set log_statement='ddl';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.26 Ensure ‘log_timezone’ Is Set Correctly: Set the correct timezone for logs. If log_timezone is not set to GMT, UTC, or as defined by your organization’s logging policy this is a fail.

show log_timezone;

  log_timezone
-----------------
 Europe/Istanbul

/* Default Value: By default, the PGDG packages will set this to match the server's timezone in the
Operating System.*/
alter system set log_timezone = 'GMT +3';

/* Reload configuretion file */
select pg_reload_conf();
  • 3.1.27 Ensure That Log Directory Is Outside the PGDATA: Place the log directory outside the main data directory. Best practice is to not write PostgreSQL logs into the PGDATA for performances reason and disk space use. Please do not forget logical volume is not enough.
show data_directory;

 data_directory
----------------
 /pg_data/data


show log_directory;

 log_directory
---------------
 /pg_log/log

3.2 Ensure the PostgreSQL Audit Extension (pgAudit) Is Enabled

  • Enable the pgAudit extension for detailed auditing of database activities. The PostgreSQL Audit Extension (pgAudit) provides detailed session and/or object audit logging via the standard PostgreSQL logging facility. The goal of pgAudit is to provide PostgreSQL users with the capability to produce audit logs often required to comply with government, financial, or ISO certifications. Basic statement logging can be provided by the standard logging facility with log_statement = all. This is acceptable for monitoring and other uses but does not provide the level of detail generally required for an audit. It is not enough to have a list of all the operations performed against the database, it must also be possible to find particular statements that are of interest to an auditor. The standard logging facility shows what the user requested, while pgAudit focuses on the details of what happened while the database was satisfying the request.
#Firstly, you can instal pgauidit package

dnf -y install pgaudit15_13

alter system set shared_preload_libraries = 'pgaudit';

ALTER SYSTEM SET pgaudit.log TO 'ddl, write';

#Reload configuretion file
select pg_reload_conf();


show pgaudit.log;

 pgaudit.log
-------------
 ddl, write


• READ: SELECT and COPY when the source is a relation or a query.
• WRITE: INSERT, UPDATE, DELETE, TRUNCATE, and COPY when the destination is a relation.
• FUNCTION: Function calls and DO blocks.
• ROLE: Statements related to roles and privileges: GRANT, REVOKE, CREATE/ALTER/DROP ROLE.
• DDL: All DDL that is not included in the ROLE class.
• MISC: Miscellaneous commands, e.g. DISCARD, FETCH, CHECKPOINT, VACUUM

4. User Access and Authorization

4.1 Ensure Sudo Is Configured Correctly

When created, the PostgreSQL user may have interactive access to the operating system, which means that the PostgreSQL user could login to the host as any other user would.

sudo grep postgres /etc/shadow | cut -d: -f1-2
# If this output is not postgres:!<something> then this is a failure.

# Execute the following command:
sudo passwd -l postgres

4.2 Ensure Sudo Is Configured Correctly

  • Review and configure sudo permissions to limit administrative access. This grants any Operating System user that is a member of the dba group the ability to use sudo -iu postgres to become the postgres user
sudo groupadd dba

useradd -m -G dba kemal

echo '%dba ALL=(postgres) PASSWD: ALL' > /etc/sudoers.d/postgres

chmod 600 /etc/sudoers.d/postgres

su - kemal

sudo -iu postgres

4.3 Ensure Excessive Administrative Privileges Are Revoked

  • With respect to PostgreSQL administrative SQL commands, only superusers should have elevated privileges. PostgreSQL regular, or application, users should not possess the ability to create roles, create new databases, manage replication, or perform any other action deemed privileged. Typically, regular users should only be granted the minimal set of privileges commensurate with managing the application
psql -c "\du+ kemal*"

                                    List of roles
 Role name | Attributes |Member of | Description
-----------+------------+-------------------------+-------------
 kemal.oz  | Superuser  | {"DBA"}  |


psql -c "ALTER ROLE kemal.oz NOSUPERUSER;"


ALTER ROLE "kemal.oz" NOSUPERUSER;


psql -c "\du+ kemal*"
                                    List of roles
 Role name | Attributes |Member of | Description
-----------+------------+-------------------------+-------------
 kemal.oz  |            | {"DBA"}  |


# Lock Out Accounts if Not Currently in Use (Manual)
ALTER ROLE "kemal.oz" NOLOGIN;

4.4 Ensure Excessive Function Privileges Are Revoked (Manual)

  • Manually review and revoke excessive function privileges. Functions in PostgreSQL can be created with the SECURITY DEFINER option. When SECURITY DEFINER functions are executed by a user, said function is run with the privileges of the user who created it, not the user who is running it.
SELECT nspname, proname, proargtypes, prosecdef, rolname, proconfig FROM pg_proc p JOIN pg_namespace n ON p.pronamespace = n.oid JOIN pg_authid a ON a.oid = p.proowner WHERE proname NOT LIKE 'pgaudit%' AND (prosecdef OR NOT proconfig IS NULL);
 nspname |                   proname                   |       proargtypes        | prosecdef | rolname  |                 proconfig
---------+---------------------------------------------+--------------------------+-----------+----------+-------------------------------------------
 public  | dblink_connect_u                            | 25 25                    | t         | postgres |
 public  | dblink_connect_u                            | 25                       | t         | postgres |
 profile | get_diffreport                              | 19 3910 1043 25 16       | f         | postgres | {search_path=profile}
 profile | get_diffreport                              | 19 1043 3910 25 16       | f         | postgres | {search_path=profile}
 profile | get_diffreport                              | 19 3910 3910 25 16       | f         | postgres | {search_path=profile}

/*In the query results, a prosecdef value of 't' on a row indicates that that
function uses privilege elevation. If elevation privileges are utilized which
are not required or are expressly forbidden by organizational guidance,
this is a fail.
*/
psql -c "ALTER FUNCTION dblink_connect_u SECURITY INVOKER;"

SELECT proname, proacl FROM pg_proc WHERE proname ='dblink_connect_u';
REVOKE EXECUTE ON FUNCTION dblink_connect_ (integer,boolean) FROM appreader;

4.5 Ensure Excessive DML Privileges Are Revoked

  • Manually review and revoke excessive Data Manipulation Language (DML) privileges.
select t.schemaname, t.tablename, u.usename,
 has_table_privilege(u.usename, t.tablename, 'select') as select,
 has_table_privilege(u.usename, t.tablename, 'insert') as insert,
 has_table_privilege(u.usename, t.tablename, 'update') as update,
 has_table_privilege(u.usename, t.tablename, 'delete') as delete
from pg_tables t, pg_user u
where t.schemaname not in ('information_schema','pg_catalog');
 schemaname | tablename |   usename   | select | insert | update | delete
------------+-----------+-------------+--------+--------+--------+--------
 public     | a         | repuser     | f      | f      | f      | f
 public     | b         | repuser     | f      | f      | f      | f
 public     | a         | admin       | f      | f      | f      | f
 public     | b         | admin       | f      | f      | f      | f
 public     | a         | replication | f      | f      | f      | f
 public     | b         | replication | f      | f      | f      | f
 public     | a         | postgres    | t      | t      | t      | t
 public     | b         | postgres    | t      | t      | t      | t
 public     | a         | kemal.oz    | f      | t      | t      | f
 public     | b         | kemal.oz    | f      | f      | f      | f



select t.tablename, u.usename,
 has_table_privilege(u.usename, t.tablename, 'select') as select,
 has_table_privilege(u.usename, t.tablename, 'insert') as insert,
 has_table_privilege(u.usename, t.tablename, 'update') as update,
 has_table_privilege(u.usename, t.tablename, 'delete') as delete
from pg_tables t, pg_user u
where t.tablename = 'a'
and u.usename in ('kemal.oz');
 tablename | usename  | select | insert | update | delete
-----------+----------+--------+--------+--------+--------
 a         | kemal.oz | f      | t      | t      | f


REVOKE update, insert  ON TABLE a FROM "kemal.oz";


select t.tablename, u.usename,
 has_table_privilege(u.usename, t.tablename, 'select') as select,
 has_table_privilege(u.usename, t.tablename, 'insert') as insert,
 has_table_privilege(u.usename, t.tablename, 'update') as update,
 has_table_privilege(u.usename, t.tablename, 'delete') as delete
from pg_tables t, pg_user u
where t.tablename = 'a'
and u.usename in ('kemal.oz');
 tablename | usename  | select | insert | update | delete
-----------+----------+--------+--------+--------+--------
 a         | kemal.oz | f      | f      | f      | f


/*
Note: For versions of PostgreSQL prior to version 15, CVE-2018-1058 is applicable and
it is recommended that all privileges be revoked from the public schema for all users on
all databases. If you have upgraded from one of these earlier releases, this CVE is not
fixed for you during an upgrade. You can correct this CVE by issuing:

https://nvd.nist.gov/vuln/detail/CVE-2018-1058
*/

REVOKE CREATE ON SCHEMA public FROM PUBLIC;

4.6 Ensure Row Level Security (RLS) Is Configured Correctly (Manual)

  • Configure Row Level Security to restrict data access based on user roles.
SELECT oid, relname, relrowsecurity FROM pg_class WHERE relrowsecurity IS TRUE;
 oid | relname | relrowsecurity
-----+---------+----------------


CREATE TABLE passwd1 (
 user_name text UNIQUE NOT NULL,
 pwhash text,
 uid int PRIMARY KEY,
 gid int NOT NULL,
 real_name text NOT NULL,
 home_phone text,
 extra_info text,
 home_dir text NOT NULL,
 shell text NOT NULL
);


SELECT oid, relname, relrowsecurity FROM pg_class WHERE relname = 'passwd';
  oid  | relname | relrowsecurity
-------+---------+----------------
 26300 | passwd  | f


CREATE USER admin;
CREATE USER bob;
CREATE USER alice;

 INSERT INTO passwd VALUES
 ('admin','xxx',0,0,'Admin1','111-222-3333',null,'/root','/bin/dash');

INSERT INTO passwd VALUES
('bob','xxx',1,1,'Bob','123-456-7890',null,'/home/bob','/bin/zsh');

INSERT INTO passwd VALUES
('alice','xxx',2,1,'Alice','098-765-4321',null,'/home/alice','/bin/zsh');

ALTER TABLE passwd ENABLE ROW LEVEL SECURITY;

SELECT oid, relname, relrowsecurity FROM pg_class WHERE relname = 'passwd';
  oid  | relname | relrowsecurity
-------+---------+----------------
 26300 | passwd  | t

CREATE POLICY admin_all ON passwd TO admin USING (true) WITH CHECK (true);

CREATE POLICY user_mod ON passwd FOR UPDATE
 USING (current_user = user_name)
 WITH CHECK (
 current_user = user_name AND
 shell IN ('/bin/bash','/bin/sh','/bin/dash','/bin/zsh','/bin/tcsh')
 );


GRANT SELECT, INSERT, UPDATE, DELETE ON passwd TO admin;

GRANT SELECT
 (user_name, uid, gid, real_name, home_phone, extra_info, home_dir, shell)
 ON passwd TO public;

GRANT UPDATE
 (pwhash, real_name, home_phone, extra_info, shell)
 ON passwd TO public;

set role admin;

table passwd;
 user_name | pwhash | uid | gid | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+--------+-----+-----+-----------+--------------+------------+-------------+-----------
 admin     | xxx    |   0 |   0 | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | xxx    |   1 |   1 | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | xxx    |   2 |   1 | Alice     | 098-765-4321 |            | /home/alice | /bin/zsh


set role alice;

table passwd;
ERROR:  permission denied for table passwd

select user_name,real_name,home_phone,extra_info,home_dir,shell from passwd;
 user_name | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+-----------+--------------+------------+-------------+-----------
 admin     | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | Alice     | 098-765-4321 |            | /home/alice | /bin/zsh


update passwd set user_name = 'joe';
ERROR:  permission denied for table passwd

update passwd set real_name = 'Alice Doe';
UPDATE 1

update passwd set real_name = 'John Doe' where user_name = 'admin';
UPDATE 0

select user_name,real_name,home_phone,extra_info,home_dir,shell from passwd;
 user_name | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+-----------+--------------+------------+-------------+-----------
 admin     | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | Alice Doe | 098-765-4321 |            | /home/alice | /bin/zsh

update passwd set real_name = 'John Doe' where user_name = 'admin1';
UPDATE 0

 select user_name,real_name,home_phone,extra_info,home_dir,shell from passwd;
 user_name | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+-----------+--------------+------------+-------------+-----------
 admin     | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | Alice Doe | 098-765-4321 |            | /home/alice | /bin/zsh


update passwd set shell = '/bin/xx';
ERROR:  new row violates row-level security policy for table "passwd"

delete from passwd;
ERROR:  permission denied for table passwd

insert into passwd (user_name) values ('xxx');
ERROR:  permission denied for table passwd

update passwd set pwhash = 'abc';
UPDATE 1

select user_name,real_name,home_phone,extra_info,home_dir,shell from passwd;
 user_name | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+-----------+--------------+------------+-------------+-----------
 admin     | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | Alice Doe | 098-765-4321 |            | /home/alice | /bin/zsh

update passwd set pwhash = 'abc';

select user_name,real_name,home_phone,extra_info,home_dir,shell from passwd;
 user_name | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+-----------+--------------+------------+-------------+-----------
 admin     | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | Alice Doe | 098-765-4321 |            | /home/alice | /bin/zsh

# Authorized user
table passwd;
 user_name | pwhash | uid | gid | real_name |  home_phone  | extra_info |  home_dir   |   shell
-----------+--------+-----+-----+-----------+--------------+------------+-------------+-----------
 admin     | xxx    |   0 |   0 | Admin1    | 111-222-3333 |            | /root       | /bin/dash
 bob       | xxx    |   1 |   1 | Bob       | 123-456-7890 |            | /home/bob   | /bin/zsh
 alice     | abc    |   2 |   1 | Alice Doe | 098-765-4321 |            | /home/alice | /bin/zsh

4.7 Ensure the set_user Extension Is Installed (Manual)

  • Install the set_user extension to safely change user identities. PostgreSQL access to the superuser database role must be controlled and audited to prevent unauthorized access. Prior to performing this audit you must create a roletree view. Here are the procedures to create this view:
CREATE OR REPLACE VIEW roletree AS
WITH RECURSIVE
roltree AS (
 SELECT u.rolname AS rolname,
        u.oid AS roloid,
        u.rolcanlogin,
        u.rolsuper,
        '{}'::name[] AS rolparents,
        NULL::oid AS parent_roloid,
        NULL::name AS parent_rolname
 FROM pg_catalog.pg_authid u
 LEFT JOIN pg_catalog.pg_auth_members m ON u.oid = m.member
 LEFT JOIN pg_catalog.pg_authid g ON m.roleid = g.oid
 WHERE g.oid IS NULL
 UNION ALL
 SELECT u.rolname AS rolname,
        u.oid AS roloid,
        u.rolcanlogin,
        u.rolsuper,
        t.rolparents || g.rolname AS rolparents,
        g.oid AS parent_roloid,
        g.rolname AS parent_rolname
 FROM pg_catalog.pg_authid u
 JOIN pg_catalog.pg_auth_members m ON u.oid = m.member
 JOIN pg_catalog.pg_authid g ON m.roleid = g.oid
 JOIN roltree t ON t.roloid = g.oid
)
SELECT rolname,
       roloid,
       rolcanlogin,
       rolsuper,
       rolparents,
       parent_roloid,
       parent_rolname
FROM roltree;

SELECT
 r.rolname,
 r.roloid,
 r.rolcanlogin,
 r.rolsuper,
 r.rolparents
FROM roletree r
ORDER BY 1;
          rolname          | roloid | rolcanlogin | rolsuper |       rolparents
---------------------------+--------+-------------+----------+------------------------
 admin                     |  16385 | t           | f        | {}
 admin1                    |  26309 | t           | f        | {}
 alice                     |  26311 | t           | f        | {}
 bob                       |  26310 | t           | f        | {}
 kemal.oz                  |  26299 | t           | f        | {}
 pg_database_owner         |   6171 | f           | f        | {}
 pg_execute_server_program |   4571 | f           | f        | {}
 pg_monitor                |   3373 | f           | f        | {pg_stat_scan_tables}
 pg_monitor                |   3373 | f           | f        | {pg_read_all_settings}
 pg_monitor                |   3373 | f           | f        | {pg_read_all_stats}
 pg_read_all_data          |   6181 | f           | f        | {}
 pg_read_all_settings      |   3374 | f           | f        | {}
 pg_read_all_stats         |   3375 | f           | f        | {}
 pg_read_server_files      |   4569 | f           | f        | {}
 pg_signal_backend         |   4200 | f           | f        | {}
 pg_stat_scan_tables       |   3377 | f           | f        | {}
 pg_write_all_data         |   6182 | f           | f        | {}
 pg_write_server_files     |   4570 | f           | f        | {}
 postgres                  |     10 | t           | t        | {}
 replication               |  16386 | t           | f        | {}
 repuser                   |  16384 | t           | f        | {}
(21 rows)

SELECT
 ro.rolname,
 ro.roloid,
 ro.rolcanlogin,
 ro.rolsuper,
 ro.rolparents
FROM roletree ro
WHERE (ro.rolcanlogin AND ro.rolsuper)
OR
(
 ro.rolcanlogin AND EXISTS
 (
 SELECT TRUE FROM roletree ri
 WHERE ri.rolname = ANY (ro.rolparents)
 AND ri.rolsuper
 )
);
 rolname  | roloid | rolcanlogin | rolsuper | rolparents
----------+--------+-------------+----------+------------
 postgres |     10 | t           | t        | {}

rpm -ivh /a/set_user_14-4.0.1-2.rhel9.x86_64.rpm

patronictl -c /etc/patroni/patroni.yml edit-config

shared_preload_libraries = 'set_user,pgaudit,somethingelse' --Required restart

select * from pg_available_extensions where name = 'set_user';
   name   | default_version | installed_version |                  comment
----------+-----------------+-------------------+--------------------------------------------
 set_user | 4.0.1           |                   | similar to SET ROLE but with added logging


create extension set_user;

select * from pg_available_extensions where name = 'set_user';
   name   | default_version | installed_version |                  comment
----------+-----------------+-------------------+--------------------------------------------
 set_user | 4.0.1           | 4.0.1             | similar to SET ROLE but with added logging

/*
Now, we use GRANT to configure each DBA role to allow it to use the set_user functions.
In the example below, we will configure my db user kemal.oz. (You would do this for each
DBA's normal user role.)
*/
grant execute on function set_user(text) to "kemal.oz","alı.oz";
-- "kemal.oz" is an unprivileged user that can run as "alı.oz" through calls to set_user.
-- "alı.oz" is an unprivileged user that can run as "kemal.oz" through calls to set_user.

grant execute on function set_user_u(text) to "kemal.oz";
-- kemal.oz is the privileged (non-superuser) role, which is able to escalate privileges to superuser with Enhanced Logging.

set role "kemal.oz";

select set_user('postgres');
ERROR: switching to superuser not allowed

 select set_user_u('postgres');
 set_user_u
------------
 OK

 select current_user, session_user;
 current_user | session_user
--------------+--------------
 postgres     | postgres

select reset_user();
 reset_user
------------
 OK

select current_user, session_user;
 current_user | session_user
--------------+--------------
 kemal.oz     | kemal.oz


ALTER USER postgres NOLOGIN;
ERROR:  must be superuser to alter superuser roles or change superuser attribute

alter user "kemal.oz" SUPERUSER;

ALTER USER postgres NOLOGIN;

REVOKE name_of_granting_role FROM kemal.oz; -- an example only REVOKE ROLE

4.8 Make Use of Predefined Roles (Manual)

  • Utilize predefined roles to simplify and secure role management.
select rolname from pg_roles where rolsuper is true;

  rolname
------------
 kemal.oz
 db_monitor
 postgres

GRANT pg_monitor TO "kemal.oz";

Default Value:
The following predefined roles exist in PostgreSQL 13.x:
• pg_read_all_data
Read all data (tables, views, sequences), as if having SELECT rights on those
objects, and USAGE rights on all schemas, even without having it explicitly. This
role does not have the role attribute BYPASSRLS set. If RLS is being used, an
administrator may wish to set BYPASSRLS on roles which this role is GRANTed to.
• pg_write_all_data
Write all data (tables, views, sequences), as if having INSERT, UPDATE, and DELETE
rights on those objects, and USAGE rights on all schemas, even without having it
explicitly. This role does not have the role attribute BYPASSRLS set. If RLS is being
used, an administrator may wish to set BYPASSRLS on roles which this role is
GRANTed to.
• pg_read_all_settings
Read all configuration variables, even those normally visible only to superusers.
• pg_read_all_stats
Read all pg_stat_* views and use various statistics related extensions, even
those normally visible only to superusers.
• pg_stat_scan_tables
Execute monitoring functions that may take ACCESS SHARE locks on tables,
potentially for a long time.
• pg_monitor
Read/execute various monitoring views and functions. This role is a member of
pg_read_all_settings, pg_read_all_stats and pg_stat_scan_tables.
• pg_database_owner
None. Membership consists, implicitly, of the current database owner.
• pg_signal_backend
Signal another backend to cancel a query or terminate its session.
• pg_read_server_files
Allow reading files from any location the database can access on the server with
COPY and other file-access functions.
pg_write_server_files
Allow writing to files in any location the database can access on the server with
COPY and other file-access functions.
• pg_execute_server_program
Allow executing programs on the database server as the user the database runs
as with COPY and other functions which allow executing a server-side program.
• pg_checkpoint
Allow executing the CHECKPOINT command.
• pg_use_reserved_connections
Allow use of connection slots reserved via reserved_connections.
• pg_create_subscription
Allow users with CREATE permission on the database to issue CREATE SUBSCRIPTION.

4.9 Ensure the Public Schema Is Protected

  • Restrict access to the public schema to prevent unauthorized changes. you need to manage the permissions on the public schema carefully.
/*
Note: For versions of PostgreSQL prior to version 15, CVE-2018-1058 is applicable and
it is recommended that all privileges be revoked from the public schema for all users on
all databases. If you have upgraded from one of these earlier releases, this CVE is not
fixed for you during an upgrade. You can correct this CVE by issuing:

https://nvd.nist.gov/vuln/detail/CVE-2018-1058
*/

REVOKE CREATE ON SCHEMA public FROM PUBLIC;

GRANT CREATE ON SCHEMA public TO "kemal.oz"; -- Grant necessary privileges to specific users or roles

/*
Periodically, you should review the current permissions on the public schema
to ensure that there are no unauthorized changes.
*/

SELECT grantee, privilege_type
FROM information_schema.role_table_grants
WHERE table_schema = 'public';

SELECT nspname, usename, has_schema_privilege(usename, nspname, 'CREATE') AS create_priv
FROM pg_namespace, pg_user
WHERE nspname = 'public';

5. Connection and Login

5.1 Do Not Specify Passwords in the Command Line

  • When a command is executed on the command line, for example
postgresql://postgres:PASSWORD@host

the password may be visible in the user’s shell/command history or in the process list, thus exposing the password to other entities on the server.

# Check the process or task list if the password is visible.
sudo ps -few

# Check the shell or command history if the password is visible.
History

#Remediation: Use the --password or -W terminal parameter without directly specifying thepassword and then enter the password when prompted.
psql -u <user> --password

5.2 Ensure PostgreSQL is Bound to an IP Address

  • By default, listen_addresses is set to localhost which prevents any and all remote TCP connections to the PostgreSQL port. Some Docker images may set listen_addesses to *. * corresponds to all available IP interfaces; thus, the PostgreSQL server then accepts TCP connections on all the server’s IPv6 and IPv4 interfaces. (The same is true for a setting of 0.0.0.0.) You can make this configuration more restrictive by setting the listen_addresses configuration option to a specific list of IPv4 or IPv6 address so that the server only accepts TCP connections on those addresses. This parameter can only be set at server start
SHOW listen_addresses;
-- If * or 0.0.0.0 is returned, this is a failure.

5.3 Ensure Login via “Local” UNIX Domain Socket Is Configured Correctly

  • Configure secure login methods for local connections. A remote host login, via SSH, is arguably the most secure means of remotely accessing and administering the PostgreSQL server. Once connected to the PostgreSQL server, using the psql client, via UNIX DOMAIN SOCKETS, while using the peer authentication method is the most secure mechanism available for local database connections. Provided a database user account of the same name of the UNIX account has already been defined in the database, even ordinary user accounts can access the cluster in a similarly highly secure manner
-- allow only postgres user logins locally via UNIX socket
# TYPE  DATABASE        USER            ADDRESS                 METHOD
# "local" is for Unix domain socket connections only
local   all             postgres                                peer

-- allow all local users via UNIX socket
local   all             all                                     peer

-- allow all local users, via UNIX socket, only if they are connecting to a db named the same as their username
local   samerole        all                                     peer

-- allow only local users, via UNIX socket, who are members of the 'rw' role in the db
local   all             +rw                                     peer

5.4 Ensure Login via “Host” TCP/IP Socket Is Configured Correctly

  • A large number of authentication methods are available for hosts connecting using TCP/IP sockets. Methods trust, password, and ident are not to be used for remote logins. Method md5 used to be the most popular and can be used in both encrypted and unencrypted sessions, however, it is vulnerable to packet replay attacks. It is recommended that scram-sha-256 be used instead of md5. Use of the gss, sspi, pam, ldap, radius, and cert methods are dependent upon the availability of external authenticating processes/services and thus are not covered here.
# The use of the "md5" authentication method is vulnerable to packet replay attacks. See line ** in file /pg_data/data/pg_hba.conf.
host    all        all             10.6.128.238/32        md5
# This is fail

host    all        all             10.10.80.238/32        scram-sha-256
# This can be pass our exam

Please read ldap and other authentication method for increase your security.

5.5 Ensure per-account connection limits are used

  • Limiting concurrent connections to a PostgreSQL server can be used to reduce the risk of Denial of Service (DoS) attacks.
SELECT rolname, rolconnlimit
FROM pg_roles
WHERE rolname NOT LIKE 'pg_%';;
-- Default Value: -1

   rolname   | rolconnlimit
-------------+--------------
 repuser     |           -1
 admin       |           -1
 replication |           -1
 admin1      |           -1
 bob         |           -1
 alice       |           -1
 kemal.oz    |           -1
 db_monitor  |           -1
 postgres    |           -1
(9 rows)

ALTER USER "kemal.oz" CONNECTION LIMIT 4; -- please set reasonable concurrent connection count

SELECT rolname, rolconnlimit
FROM pg_roles
WHERE rolname NOT LIKE 'pg_%';;
   rolname   | rolconnlimit
-------------+--------------
 repuser     |           -1
 admin       |           -1
 replication |           -1
 admin1      |           -1
 bob         |           -1
 alice       |           -1
 db_monitor  |           -1
 postgres    |           -1
 kemal.oz    |            4

5.6 Ensure Password Complexity Is Configured

  • Enforce strong password policies. Password complexity configuration is crucial to restrict unauthorized access to data. By default, PostgreSQL doesn’t provide for password complexity. Moreover, many compliance frameworks such as PCI DSS, and HIPPA require both password complexity and length. It is worth stating that the NIST 800–63B Password Guidelines publication is a good reference of authentication management.
SHOW shared_preload_libraries;
shared_preload_libraries
--------------------------
set_user,pgaudit

SHOW dynamic_library_path;
dynamic_library_path
----------------------
$libdir

vi ${PGDATA}/postgresql.conf
shared_preload_libraries = 'pgaudit,$libdir/passwordcheck,somethingelse'
-- This changes need to restart

create user deneme1 password 'test123';
ERROR:  password is too short
-- password required at least 8 charackter

5.7 Ensure Authentication Timeout and Delay Are Well Configured

  • Set appropriate authentication timeouts and delays to prevent brute-force attacks. You can edit postgresql.conf below parameter
connection_timeout = 3s  # example timeout of 3 seconds

If you can masquerade your eggs like haproxy you can edit haproxy configuration file. As show below;

#/etc/haproxy/haproxy.cfg

timeout connect 3s

5.8 Ensure SSL Is Used for Client Connection

  • Enable SSL to encrypt client connections. Secure login methods for remote connections. A large number of authentication METHODs are available for hosts connecting using TCP/IP sockets, including: • trust • reject • md5 • scram-sha-256 • password • gss • sspi • ident • pam • ldap” • radius • cert. You can visit to apply Securing PostgreSQL with SSL Encryption article for detail.
psql 'host=10.10.80.68 user=postgres sslmode=require'
# output
psql: error: connection to server at "10.5.56.67", port 5432 failed: server does not support SSL, but SSL was required
# If output like this then this is a failure. Please read article above

psql 'host=10.10.80.68 user=postgres sslmode=require'
# output
SSL connection (protocol: TLSv1.3, cipher: TLS_AES_256_GCM_SHA384, bits: 256, compression: off)

1. Use TYPE hostssl when administrating the database cluster as a superuser.
2. Use TYPE hostnossl for performance purposes and when DML operations are deemed safe without SSL connections.

Additional Information

  1. Use TYPE hostssl when administrating the database cluster as a superuser.
  2. Use TYPE hostnossl for performance purposes and when DML operations are deemed safe without SSL connections.

5.9 Ensure Authorized IP Address Ranges Are Not Too Large

  • Restrict IP address ranges for connections to minimize exposure. P addressing uses a 32-bit address to identify each host on an IPv4 network. To make addresses easier to read, they are written in dotted decimal notation, each address being four octets in length. For example, address 00001010000000010000000100000001 in binary is written as 10.1.1.1. However, the most important thing is range in terms of subnet that dividing a network into at least two separate networks. Please do not forget allowing a too large range of Ip addresses to connect to PostgreSQL cluster multiply the risks unnecessarily
Below is a table providing typical subnets for IPv4.

Prefix size Network mask Usable hosts per subnet
/1           128.0.0.0      2,147,483,646
/2           192.0.0.0      1,073,741,822
/3           224.0.0.0      536,870,910
/4           240.0.0.0      268,435,454
/5           248.0.0.0      134,217,726
/6           252.0.0.0      67,108,862
/7           254.0.0.0      33,554,430
Class A
/8          255.0.0.0       16,777,214
/9          255.128.0.0     8,388,606
/10         255.192.0.0     4,194,302
/11         255.224.0.0     2,097,150
/12         255.240.0.0     1,048,574
/13         255.248.0.0     524,286
/14         255.252.0.0     262,142
/15         255.254.0.0     131,070
Class B
/16         255.255.0.0     65,534
/17         255.255.128.0   32,766
/18         255.255.192.0   16,382
/19         255.255.224.0   8,190
/20         255.255.240.0   4,094
/21         255.255.248.0   2,046
/22         255.255.252.0   1,022
/23         255.255.254.0   510
Class C
/24         255.255.255.0   254
/25         255.255.255.128 126
/26         255.255.255.192 62
/27         255.255.255.224 30
/28         255.255.255.240 14
/29         255.255.255.248 6
/30         255.255.255.252 2
/31         255.255.255.254 0
/32         255.255.255.255 0

5.10 Ensure Specific Database and Users Are Used

  • Limit access to specific databases and users. The keyword “all” in the database and user part of the pg_hba.conf rules can allow any user to connect to any database, it is recommended to restrict the connection to specific user and database
\h create role
Command:     CREATE ROLE
Description: define a new database role
Syntax:
CREATE ROLE name [ [ WITH ] option [ ... ] ]

where option can be:

      SUPERUSER | NOSUPERUSER
    | CREATEDB | NOCREATEDB
    | CREATEROLE | NOCREATEROLE
    | INHERIT | NOINHERIT
...

A good practice when creating roles is to add a role with the CREATEROLE and
CREATEDB attributes but not the SUPERUSER. And use this role to add any other
role and database you need to create.

CREATE ROLE admin WITH
  LOGIN
  NOSUPERUSER
  NOINHERIT
  CREATEDB
  CREATEROLE
  NOREPLICATION
  CONNECTION LIMIT 10
  PASSWORD 'test123'
  VALID UNTIL '2024-04-19 17:00:00+03';

create role "user1" in role "admin";
alter user "user1" login;

"""
The role attributes LOGIN, SUPERUSER, CREATEDB, and CREATEROLE can be thought
of as special privileges,  but they are never inherited as ordinary privileges
on database objects are.  You must actually SET ROLE to a specific role having
one of these attributes in order to make use of the attribute.
"""

SELECT * FROM pg_roles ;
\du

"""
you can manage your pg_hba configuration file your role. Below passed example
admin role can be login to clusterdb. You can create a lot of role your requriments.
"""


# TYPE  DATABASE        USER            ADDRESS                 METHOD
host    all             all             10.80.208.0/24          scram-sha-256
""" Like tihs configurations fail our exam"""

# TYPE  DATABASE        USER            ADDRESS                 METHOD
host    clusterdb       admin           10.80.208./21           scram-sha-256
# Like tihs configurations pass our exam

5.11 Ensure Superusers Are Not Allowed to Connect Remotely

  • Prevent superuser remote connections to enhance security. Allowing a PostgreSQL superuser to connect to a database from a remote host is dangerous, best is to only allow the superuser(s) to connect locally with a peer authentication. If some advanced privileges are required, best is to use the PostgreSQL predefined roles.
show listen_addresses;
 listen_addresses
------------------
 10.70.12.23
(1 row)
**10.70.12.23: This is server ip4. Please avoid to use * or 0.0.0.0

/*
If You are admin you can edit conf file. Please do not forget other parameter
user cannot be all. If you give this permission. This is fail.
*/

TYPE    DATABASE   USER                 ADDRESS                 METHOD
Host    all        postgres             10.10.120.120/32        scram-sha-256

**10.10.120.120: Admin

5.12 Ensure That ‘password_encryption’ Is Correctly Set

  • Use strong encryption for stored passwords. PostgreSQL allow to set password encryption, default is now ‘scram-sha-256’ but it can be set to ‘md5’ or ‘trust’ which is insecure. Consider other methods your compan policies; • reject • scram-sha-256 • password • gss • sspi • ident • pam • ldap” • radius • cert.
TYPE    DATABASE   USER                 ADDRESS                 METHOD
Host    all        postgres             10.10.120.0/24          trust
Host    all        postgres             10.10.120.0/24          md5
-- This is failed

TYPE    DATABASE   USER                 ADDRESS                 METHOD
Host    all        postgres             10.10.120.0/24          scram-sha-256
-- This is passed

6. PostgreSQL Settings

6.1 Understanding Attack Vectors and Runtime Parameters

  • Gain a thorough understanding of potential attack vectors and how to configure runtime parameters.
Examples;
--------------
1. Weak Authentication
2. SQL injection
3. Privilege abuse
4. Excessive privileges
5. Phishing
6. Inadequate logging and weak auditing
7. Denial of service
8. Exploiting unpatched services
9. Insecure system architecture
10. Inadequate Backup

6.2 Ensure ‘Backend’ Runtime Parameters Are Configured Correctly

  • Configure backend parameters to enhance security and performance. A denial of service is possible by denying the use of indexes and by slowing down client access to an unreasonable level. Unsanctioned behavior can be introduced by introducing rogue libraries which can then be called in a database session. Logging can be altered and obfuscated inhibiting root cause analysis. All changes made on this level will affect the overall behavior of the server. These changes can only be affected by a server restart after the parameters have been altered in the configuration files.
SELECT name, setting FROM pg_settings WHERE context IN
('backend','superuser-backend') ORDER BY 1;

         name          | setting
-----------------------+---------
 ignore_system_indexes | off
 jit_debugging_support | off
 jit_profiling_support | off
 log_connections       | on
 log_disconnections    | on
 post_auth_delay       | 0

ps -few | grep -E -- '[p]ost.*-[D]'

""" Output"""
postgres 2744612       1  0 Jun10 ?
00:00:04 /usr/pgsql-14/bin/postgres -D /var/data/
--config-file=/var/data/postgresql.conf
--listen_addresses=10.5.56.67 --port=5432
--cluster_name=denemek --wal_level=replica
--hot_standby=on
--max_connections=100
--max_wal_senders=10
--max_prepared_transactions=0
--max_locks_per_transaction=64
--track_commit_timestamp=off
--max_replication_slots=10
--max_worker_processes=8
--wal_log_hints=on

6.3 Ensure ‘Postmaster’ Runtime Parameters Are Configured Correctly (Manual)

  • Manually review and configure postmaster parameters. The postmaster process is the supervisory process that assigns a backend process to an incoming client connection. The postmaster manages key runtime parameters that are either shared by all backend connections or needed by the postmaster process itself to run. The following parameters can only be set at server start by the owner of the PostgreSQL server process and cluster, typically the UNIX user account postgres. Therefore, all exploits require the successful compromise of either that UNIX account or the postgres superuser account itself.
SELECT name, setting FROM pg_settings WHERE context = 'postmaster'
ORDER BY 1;
                name                 |            setting
-------------------------------------+--------------------------------
 archive_mode                        | on
 autovacuum_freeze_max_age           | 200000000
 autovacuum_max_workers              | 3
 autovacuum_multixact_freeze_max_age | 400000000
 bonjour                             | off
 bonjour_name                        |
 cluster_name                        | denemek
 config_file                         | /var/data/postgresql.conf
 data_directory                      | /var/data
 data_sync_retry                     | off
 dynamic_shared_memory_type          | posix
 event_source                        | PostgreSQL
 external_pid_file                   |
 hba_file                            | /var/data/pg_hba.conf
 hot_standby                         | on
 huge_pages                          | try
 huge_page_size                      | 0
 ident_file                          | /var/data/pg_ident.conf
 ignore_invalid_pages                | off
 jit_provider                        | llvmjit
 listen_addresses                    | 10.20.23.12
 logging_collector                   | on
 max_connections                     | 100
 max_files_per_process               | 1000
 max_locks_per_transaction           | 64
 max_logical_replication_workers     | 4
 max_pred_locks_per_transaction      | 64
 max_prepared_transactions           | 0
 max_replication_slots               | 10
 max_wal_senders                     | 10
 max_worker_processes                | 8
 min_dynamic_shared_memory           | 0
 old_snapshot_threshold              | -1
 port                                | 5432
 recovery_target                     |
 recovery_target_action              | pause
 recovery_target_inclusive           | on
 recovery_target_lsn                 |
 recovery_target_name                |
 recovery_target_time                |
 recovery_target_timeline            | latest
 recovery_target_xid                 |
 shared_buffers                      | 16384
 shared_memory_type                  | mmap
 shared_preload_libraries            | set_user,$libdir/passwordcheck
 superuser_reserved_connections      | 3
 track_activity_query_size           | 1024
 track_commit_timestamp              | off
 unix_socket_directories             | /var/run/postgresql, /tmp
 unix_socket_group                   |
 unix_socket_permissions             | 0777
 wal_buffers                         | 512
 wal_level                           | replica
 wal_log_hints                       | on
(54 rows)


ps -few | grep -E -- '[p]ost.*-[D]'

""" Output"""
postgres 2744612       1  0 Jun10 ?
00:00:04 /usr/pgsql-14/bin/postgres -D /var/data/
--config-file=/var/data/postgresql.conf
--listen_addresses=10.5.56.67 --port=5432
--cluster_name=denemek --wal_level=replica
--hot_standby=on
--max_connections=100
--max_wal_senders=10
--max_prepared_transactions=0
--max_locks_per_transaction=64
--track_commit_timestamp=off
--max_replication_slots=10
--max_worker_processes=8
--wal_log_hints=on

6.4 Ensure ‘SIGHUP’ Runtime Parameters Are Configured Correctly

  • Manually configure SIGHUP parameters for signal handling. In order to define server behavior and optimize server performance, the server’s superuser has the privilege of setting these parameters which are found in the configuration files postgresql.conf and pg_hba.conf. Alternatively, those parameters found in postgresql.conf can also be changed using a server login session and executing the SQL command ALTER SYSTEM which writes its changes in the configuration file postgresql.auto.conf. All changes made on this level will affect the overall behavior of the server. These changes can be effected by editing the PostgreSQL configuration files and by either executing a server SIGHUP from the command line or, as superuser postgres, executing the SQL command select pg_reload_conf(). A denial of service is possible by the over-allocating of limited resources, such as RAM. Data can be corrupted by allowing damaged pages to load or by changing parameters to reinterpret values in an unexpected fashion, e.g. changing the time zone. Client messages can be altered in such a way as to interfere with the application logic. Logging can be altered and obfuscated inhibiting root cause analysis.
SELECT name, setting FROM pg_settings WHERE context = 'sighup'
ORDER BY 1;
                  name                  |                                                                    setting
----------------------------------------+-----------------------------------------------------------------------------------------------------------------------------------------------
 archive_cleanup_command                |
 archive_command                        | pgbackrest --stanza=cbs_backup archive-push %p
 archive_timeout                        | 0
 authentication_timeout                 | 60
 autovacuum                             | on
 autovacuum_analyze_scale_factor        | 0.1
 autovacuum_analyze_threshold           | 50
 autovacuum_naptime                     | 60
 autovacuum_vacuum_cost_delay           | 2
 autovacuum_vacuum_cost_limit           | -1
 autovacuum_vacuum_insert_scale_factor  | 0.2
 autovacuum_vacuum_insert_threshold     | 1000
 autovacuum_vacuum_scale_factor         | 0.2
 autovacuum_vacuum_threshold            | 50
 autovacuum_work_mem                    | -1
 bgwriter_delay                         | 200
 bgwriter_flush_after                   | 64
 bgwriter_lru_maxpages                  | 100
 bgwriter_lru_multiplier                | 2
 checkpoint_completion_target           | 0.9
 checkpoint_flush_after                 | 32
 checkpoint_timeout                     | 300
 checkpoint_warning                     | 30
 db_user_namespace                      | off
 fsync                                  | on
 full_page_writes                       | on
 hot_standby_feedback                   | off
 krb_caseins_users                      | off
 krb_server_keyfile                     | FILE:/etc/sysconfig/pgsql/krb5.keytab
 log_autovacuum_min_duration            | -1
 log_checkpoints                        | off
 log_destination                        | stderr
 log_directory                          | log
 log_file_mode                          | 0600
 log_filename                           | postgresql-%a.log
 log_hostname                           | off
 log_line_prefix                        | %m [%p]
 log_recovery_conflict_waits            | off
 log_rotation_age                       | 1440
 log_rotation_size                      | 0
 log_timezone                           | US/Eastern
 log_truncate_on_rotation               | on
 max_pred_locks_per_page                | 2
 max_pred_locks_per_relation            | -2
 max_slot_wal_keep_size                 | -1
 max_standby_archive_delay              | 30000
 max_standby_streaming_delay            | 30000
 max_sync_workers_per_subscription      | 2
 max_wal_size                           | 1024
 min_wal_size                           | 80
 pre_auth_delay                         | 0
 primary_conninfo                       | user=repuser passfile=/tmp/pgpass host=10.5.56.67 port=5432 sslmode=prefer application_name=pg_node2 gssencmode=prefer channel_binding=prefer
 primary_slot_name                      | pg_node2
 promote_trigger_file                   |
 recovery_end_command                   |
 recovery_init_sync_method              | fsync
 recovery_min_apply_delay               | 0
 remove_temp_files_after_crash          | on
 restart_after_crash                    | on
 restore_command                        | pgbackrest --stanza=cbs_backup archive-get %f "%p"
 set_user.block_alter_system            | on
 set_user.block_copy_program            | on
 set_user.block_log_statement           | on
 set_user.exit_on_error                 | on
 set_user.nosuperuser_target_allowlist  | *
 set_user.superuser_allowlist           | *
 set_user.superuser_audit_tag           | AUDIT
 ssl                                    | on
 ssl_ca_file                            | /var/data/root.crt
 ssl_cert_file                          | /var/data/server.crt
 ssl_ciphers                            | HIGH:MEDIUM:+3DES:!aNULL
 ssl_crl_dir                            |
 ssl_crl_file                           |
 ssl_dh_params_file                     |
 ssl_ecdh_curve                         | prime256v1
 ssl_key_file                           | server.key
 ssl_max_protocol_version               |
 ssl_min_protocol_version               | TLSv1.2
 ssl_passphrase_command                 |
 ssl_passphrase_command_supports_reload | off
 ssl_prefer_server_ciphers              | on
 stats_temp_directory                   | pg_stat_tmp
 synchronous_standby_names              |
 syslog_facility                        | local0
 syslog_ident                           | postgres
 syslog_sequence_numbers                | on
 syslog_split_messages                  | on
 trace_recovery_messages                | log
 vacuum_defer_cleanup_age               | 0
 wal_keep_size                          | 128
 wal_receiver_create_temp_slot          | off
 wal_receiver_status_interval           | 10
 wal_receiver_timeout                   | 60000
 wal_retrieve_retry_interval            | 5000
 wal_sync_method                        | fdatasync
 wal_writer_delay                       | 200
 wal_writer_flush_after                 | 128
(97 rows)

6.5 Ensure ‘Superuser’ Runtime Parameters Are Configured Correctly (Manual)

  • Manually configure parameters that apply to superusers.
SELECT name, setting FROM pg_settings WHERE context = 'superuser' ORDER BY 1;
            name             |   setting
-----------------------------+-------------
 allow_in_place_tablespaces  | off
 allow_system_table_mods     | off
 backtrace_functions         |
 commit_delay                | 0
 compute_query_id            | auto
 deadlock_timeout            | 1000
 debug_discard_caches        | 0
 dynamic_library_path        | $libdir
 ignore_checksum_failure     | off
 jit_dump_bitcode            | off
 lc_messages                 | en_US.UTF-8
 lo_compat_privileges        | off
 log_duration                | off
 log_error_verbosity         | default
 log_executor_stats          | off
 log_lock_waits              | off
 log_min_duration_sample     | -1
 log_min_duration_statement  | -1
 log_min_error_statement     | error
 log_min_messages            | warning
 log_parameter_max_length    | -1
 log_parser_stats            | off
 log_planner_stats           | off
 log_replication_commands    | off
 log_statement               | none
 log_statement_sample_rate   | 1
 log_statement_stats         | off
 log_temp_files              | -1
 log_transaction_sample_rate | 0
 max_stack_depth             | 2048
 session_preload_libraries   |
 session_replication_role    | origin
 temp_file_limit             | -1
 track_activities            | on
 track_counts                | on
 track_functions             | none
 track_io_timing             | off
 track_wal_io_timing         | off
 update_process_title        | on
 wal_compression             | off
 wal_consistency_checking    |
 wal_init_zero               | on
 wal_recycle                 | on
 zero_damaged_pages          | off
(44 rows)

6.6 Ensure ‘User’ Runtime Parameters Are Configured Correctly (Manual)

  • Manually configure parameters that apply to regular users. These PostgreSQL runtime parameters are managed at the user account (ROLE) level. In order to improve performance and optimize features, a ROLE has the privilege of setting numerous parameters in a transaction, session, or entity attribute. Any ROLE can alter any of these parameters. A denial of service is possible by the over-allocating of limited resources, such as RAM. Changing VACUUM parameters can force a server shutdown which is standard procedure preventing data corruption from transaction ID wraparound. Data can be corrupted by changing parameters to reinterpret values in an unexpected fashion, e.g. changing the time zone. Logging can be altered and obfuscated to inhibit root cause analysis.
SELECT name, setting FROM pg_settings WHERE context = 'user' ORDER BY 1;
                name                 |      setting
-------------------------------------+--------------------
 application_name                    | psql
 array_nulls                         | on
 backend_flush_after                 | 0
 backslash_quote                     | safe_encoding
 bytea_output                        | hex
 check_function_bodies               | on
 client_connection_check_interval    | 0
 client_encoding                     | UTF8
 client_min_messages                 | notice
 commit_siblings                     | 5
 constraint_exclusion                | partition
 cpu_index_tuple_cost                | 0.005
 cpu_operator_cost                   | 0.0025
 cpu_tuple_cost                      | 0.01
 cursor_tuple_fraction               | 0.1
 DateStyle                           | ISO, MDY
 debug_pretty_print                  | on
 debug_print_parse                   | off
 debug_print_plan                    | off
 debug_print_rewritten               | off
 default_statistics_target           | 100
 default_table_access_method         | heap
 default_tablespace                  |
 default_text_search_config          | pg_catalog.english
 default_toast_compression           | pglz
 default_transaction_deferrable      | off
 default_transaction_isolation       | read committed
 default_transaction_read_only       | off
 effective_cache_size                | 524288
 effective_io_concurrency            | 1
 enable_async_append                 | on
 enable_bitmapscan                   | on
 enable_gathermerge                  | on
 enable_hashagg                      | on
 enable_hashjoin                     | on
 enable_incremental_sort             | on
 enable_indexonlyscan                | on
 enable_indexscan                    | on
 enable_material                     | on
 enable_memoize                      | on
 enable_mergejoin                    | on
 enable_nestloop                     | on
 enable_parallel_append              | on
 enable_parallel_hash                | on
 enable_partition_pruning            | on
 enable_partitionwise_aggregate      | off
 enable_partitionwise_join           | off
 enable_seqscan                      | on
 enable_sort                         | on
 enable_tidscan                      | on
 escape_string_warning               | on
 exit_on_error                       | off
 extra_float_digits                  | 1
 force_parallel_mode                 | off
 from_collapse_limit                 | 8
 geqo                                | on
 geqo_effort                         | 5
 geqo_generations                    | 0
 geqo_pool_size                      | 0
 geqo_seed                           | 0
 geqo_selection_bias                 | 2
 geqo_threshold                      | 12
 gin_fuzzy_search_limit              | 0
 gin_pending_list_limit              | 4096
 hash_mem_multiplier                 | 1
 idle_in_transaction_session_timeout | 0
 idle_session_timeout                | 0
 IntervalStyle                       | postgres
 jit                                 | on
 jit_above_cost                      | 100000
 jit_expressions                     | on
 jit_inline_above_cost               | 500000
 jit_optimize_above_cost             | 500000
 jit_tuple_deforming                 | on
 join_collapse_limit                 | 8
 lc_monetary                         | en_US.UTF-8
 lc_numeric                          | en_US.UTF-8
 lc_time                             | en_US.UTF-8
 local_preload_libraries             |
 lock_timeout                        | 0
 logical_decoding_work_mem           | 65536
 log_parameter_max_length_on_error   | 0
 maintenance_io_concurrency          | 10
 maintenance_work_mem                | 65536
 max_parallel_maintenance_workers    | 2
 max_parallel_workers                | 8
 max_parallel_workers_per_gather     | 2
 min_parallel_index_scan_size        | 64
 min_parallel_table_scan_size        | 1024
 parallel_leader_participation       | on
 parallel_setup_cost                 | 1000
 parallel_tuple_cost                 | 0.1
 password_encryption                 | scram-sha-256
 plan_cache_mode                     | auto
 quote_all_identifiers               | off
 random_page_cost                    | 4
 row_security                        | on
 search_path                         | "$user", public
 seq_page_cost                       | 1
 standard_conforming_strings         | on
 statement_timeout                   | 0
 synchronize_seqscans                | on
 synchronous_commit                  | on
 tcp_keepalives_count                | 0
 tcp_keepalives_idle                 | 0
 tcp_keepalives_interval             | 0
 tcp_user_timeout                    | 0
 temp_buffers                        | 1024
 temp_tablespaces                    |
 TimeZone                            | Europe/Istanbul
 timezone_abbreviations              | Default
 trace_notify                        | off
 trace_sort                          | off
 transaction_deferrable              | off
 transaction_isolation               | read committed
 transaction_read_only               | on
 transform_null_equals               | off
 vacuum_cost_delay                   | 0
 vacuum_cost_limit                   | 200
 vacuum_cost_page_dirty              | 20
 vacuum_cost_page_hit                | 1
 vacuum_cost_page_miss               | 2
 vacuum_failsafe_age                 | 1600000000
 vacuum_freeze_min_age               | 50000000
 vacuum_freeze_table_age             | 150000000
 vacuum_multixact_failsafe_age       | 1600000000
 vacuum_multixact_freeze_min_age     | 5000000
 vacuum_multixact_freeze_table_age   | 150000000
 wal_sender_timeout                  | 60000
 wal_skip_threshold                  | 2048
 work_mem                            | 4096
 xmlbinary                           | base64
 xmloption                           | content
(133 rows)

6.7 Ensure FIPS 140–2 OpenSSL Cryptography Is Used

  • Use FIPS 140–2 compliant cryptography for enhanced security. Install, configure, and use OpenSSL on a platform that has a NIST certified FIPS 140–2 installation of OpenSSL. This provides PostgreSQL instances the ability to generate and validate cryptographic hashes to protect unclassified information requiring confidentiality and cryptographic protection, in accordance with the data owner’s requirements. Configure OpenSSL to be FIPS compliant as PostgreSQL uses OpenSSL for cryptographic modules. To configure OpenSSL to be FIPS 140–2 compliant, see the official RHEL Documentation.
fips-mode-setup --check

#Output
Installation of FIPS modules is not completed.
FIPS mode is disabled.

fips-mode-setup --enable
#Output
Kernel initramdisks are being regenerated. This might take some time.
Setting system policy to FIPS
Note: System-wide crypto policies are applied on application start-up.
It is recommended to restart the system for the change of policies
to fully take place.
FIPS mode will be enabled.
Please reboot the system for the setting to take effect.

fips-mode-setup --check
#Output
FIPS mode is enabled.

openssl version
#Output
OpenSSL 3.0.7 1 Nov 2022 (Library: OpenSSL 3.0.7 1 Nov 2022)

6.8 Ensure TLS Is Enabled and Configured Correctly

  • Enable and properly configure TLS for secure communication. If TLS is not enabled and configured correctly, this increases the risk of data being compromised in transit.
SHOW ssl;
ssl - - - off (1 row)

SELECT name, setting, source FROM pg_settings WHERE name = 'ssl';

 name | setting | source
- - -+ - - - - -+ - - - - - - - - - -
ssl | off | default
(1 row)

If your output like this above, please read the Securing PostgreSQL with SSL Encryption. However, do not forget A self-signed certificate can be used for testing. On the other hand, a certificate signed by a certificate authority (CA) (either one of the global CAs or a local one) should be used in production so that clients can verify the server’s identity. If all the database clients are local to the organization, using a local CA is recommended

6.9 Ensure a Cryptographic Extension Is Installed

  • Install and use cryptographic extensions for data encryption. When considering or undertaking any form of encryption, it is critical to understand the state of the encrypted data at all stages of the data lifecycle. The use of pgcrypto ensures that the data at rest in the tables (and therefore on disk) is encrypted, but for the data to be accessed by any users or applications, said users/applications will, by necessity, have access to the encrypt and decrypt keys and the data in question will be encrypted/decrypted in memory and then transferred to/from the user/application in that form
SELECT * FROM pg_available_extensions WHERE name='pgcrypto';
   name   | default_version | installed_version |         comment
----------+-----------------+-------------------+-------------------------
 pgcrypto | 1.3             |                   | cryptographic functions


CREATE EXTENSION pgcrypto;
--The pgcrypto extension is included with the PostgreSQL 'contrib' package. Although included, it needs to be created in the database

SELECT * FROM pg_available_extensions WHERE name='pgcrypto';
   name   | default_version | installed_version |         comment
----------+-----------------+-------------------+-------------------------
 pgcrypto | 1.3             | 1.3               | cryptographic functions

6.10 Ensure a Data Anonymization Extension Is Installed

Use data anonymization extensions to protect sensitive information. Also, you can read this Enhancing Data Security in PostgreSQL: Using pgcrypto and Anonymizer Extensions

dependencies:
-------------
ddlx_14
python3-faker

rpm -iv ddlx_14-0.27-1PGDG.rhel9.noarch.rpm
rpm -iv python3-faker-13.3.3-1.el9.noarch.rpm
rpm -iv postgresql_anonymizer_14-1.1.0-1.rhel9.x86_64.rpm

create database test;
ALTER DATABASE test SET session_preload_libraries = 'anon';  -- if this is not apllyied your database please configure global preload libaries
\c test;
CREATE EXTENSION anon CASCADE;
SELECT anon.init();


create database employee;

\c employee;

CREATE TABLE people (
    id INT,
    firstname VARCHAR(10),
    lastname VARCHAR(10),
    phone VARCHAR(15)
);

INSERT INTO people (id, firstname, lastname, phone) VALUES (1, 'Kemal', 'Oz', '9012345678');

create role hr LOGIN;

GRANT SELECT ON people TO hr;

select * from people;
 id | firstname | lastname |   phone
----+-----------+----------+------------
  1 | Kemal     | Oz       | 9012345678


CREATE EXTENSION IF NOT EXISTS anon CASCADE;
SELECT anon.start_dynamic_masking();

CREATE ROLE hr LOGIN;
GRANT SELECT ON people TO hr;
SECURITY LABEL FOR anon ON ROLE hr IS 'MASKED';

SECURITY LABEL FOR anon ON COLUMN people.lastname IS 'MASKED WITH FUNCTION anon.fake_last_name()';
SECURITY LABEL FOR anon ON COLUMN people.phone IS 'MASKED WITH FUNCTION anon.partial(phone,2,$$******$$,2)';


employee=> select * from people;
 id | firstname |  lastname  |   phone
----+-----------+------------+------------
  1 | Kemal     | Wintheiser | 90******78

select * from people;
 id | firstname | lastname |   phone
----+-----------+----------+------------
  1 | Kemal     | Kshlerin | 90******78

7. Replication

7.1 Ensure a Replication-Only User Is Created and Used for Streaming Replication

  • Create a dedicated replication user with limited permissions.

Create a Replication User: Create a dedicated user with replication privileges.

CREATE ROLE replication_user WITH REPLICATION PASSWORD 'test123';

7.2 Ensure Logging of Replication Commands Is Configured

  • Log replication commands for auditing and monitoring.
    log_autovacuum_min_duration: 5000
    log_checkpoints: true
    log_connections: true
    logging_collector: true
    log_directory: /pg_log/log
    log_disconnections: true
    log_filename: postgresql-%Y-%m-%d_%H%M%S.log
    log_line_prefix: '%t [%p]: [%l-1] user=%u,db=%d,host=%h,app=%a '
    log_rotation_age: 1d
    log_lock_waits: true
    log_min_duration_statement: 5000 # Logs all statements, including those with 5000s duration
    log_statement: ddl
    log_temp_files: 0

7.3 Ensure Base Backups Are Configured and Functional

7.4 Ensure WAL Archiving Is Configured and Functional

  • Configure and maintain WAL archiving for point-in-time recovery.
archive_command: pgbackrest --stanza=cbs_backup archive-push %p
archive_mode: true
archive_timeout: 60

7.5 Ensure Streaming Replication Parameters Are Configured Correctly

8. Special Configuration Considerations

8.1 Ensure PostgreSQL Subdirectory Locations Are Outside the Data Cluster

  • Place subdirectories outside the main data directory to enhance security and manageability. Please do not forget logical volume is not enough. You must use physical volume for best practice. Also, you can divide your machine file server like this below
/pg_data
/pg_temp
/pg_log
/pg_wal

8.2 Ensure the Backup and Restore Tool, ‘pgBackRest’, Is Installed and Configured

8.3 Ensure Miscellaneous Configuration Settings Are Correct (Manual)

  • Manually review and configure any additional settings to ensure comprehensive security.
### 8.3 Ensure Miscellaneous Configuration Settings Are Correct (Manual)

1. **Review Security Policies and Procedures**:
   - Ensure your organization's security policies and procedures are up-to-date.
   - Verify that all security policies are being enforced consistently across all systems.

2. **Check for Default Settings**:
   - Identify and change any default settings, especially those related to security, to customized and secure values.
   - Disable or remove any unnecessary default accounts or services.

3. **Audit and Logging**:
   - Ensure that logging is enabled for all critical systems and applications.
   - Verify that log data is being monitored, analyzed, and stored securely.
   - Implement log rotation and retention policies.

4. **Review User Accounts and Permissions**:
   - Conduct regular audits of user accounts and permissions.
   - Ensure that users have the minimum necessary permissions (principle of least privilege).
   - Remove or disable inactive or unnecessary accounts promptly.

5. **Network Configuration**:
   - Review firewall rules and access control lists (ACLs) to ensure they are configured correctly and are up-to-date.
   - Check for any open ports and services that are not required and close them.
   - Ensure that network devices have strong, unique passwords and that management interfaces are secured.

6. **Update and Patch Management**:
   - Verify that all systems and applications are running the latest security patches and updates.
   - Implement a regular patch management process.

7. **Application Security**:
   - Review application configurations to ensure they are secure.
   - Ensure that applications are using secure protocols (e.g., HTTPS instead of HTTP).
   - Conduct regular security assessments and code reviews.

8. **Data Protection**:
   - Ensure that sensitive data is encrypted at rest and in transit.
   - Verify that data backup processes are in place and that backups are stored securely.
   - Implement data loss prevention (DLP) measures.

9. **Incident Response**:
   - Review and update the incident response plan regularly.
   - Conduct regular incident response drills and ensure that the incident response team is trained and ready.

10. **Physical Security**:
    - Ensure that physical access to critical systems and data is restricted and monitored.
    - Implement measures like access cards, biometric scanners, and surveillance cameras.

11. **Mobile Device Management**:
    - Ensure that all mobile devices accessing company data are managed and secured.
    - Implement policies for device encryption, remote wipe, and regular updates.

12. **Review Security Settings in Cloud Services**:
    - Verify that cloud services are configured according to best security practices.
    - Ensure that cloud storage, computing, and network configurations follow your organization's security policies.

13. **Third-party and Vendor Management**:
    - Ensure that third-party vendors comply with your security requirements.
    - Review third-party agreements and conduct regular security assessments of their systems and practices.

By adhering to CIS benchmarks, you can significantly enhance the security and integrity of your PostgreSQL databases, ensuring they are well-protected against potential threats. These benchmarks provide a comprehensive set of best practices for securing PostgreSQL environments, covering critical areas such as authentication, access controls, encryption, and logging. Implementing these recommendations helps mitigate risks associated with unauthorized access, data breaches, and other security vulnerabilities. Moreover, CIS benchmarks are continuously updated to reflect the latest security threats and industry standards, ensuring that your security practices remain current and effective. By following these guidelines, organizations can demonstrate a proactive approach to database security, instilling confidence among stakeholders and customers regarding the protection of sensitive information. In conclusion, adopting CIS benchmarks for PostgreSQL is a vital step in fortifying your database infrastructure. It not only enhances the overall security posture but also contributes to operational efficiency by preventing security incidents and reducing the need for reactive measures. Therefore, investing in these best practices is a prudent decision for any organization aiming to safeguard its data assets and maintain a robust security framework. For more detailed and technical articles like this, keep following our blog on Medium. If you have any questions or need further assistance, feel free to reach out in the comments below and directly.
