Logical Replication in Postgres

Logical Replication in Postgres

Introduction to Logical Replication

Logical replication in PostgreSQL is designed to replicate data changes at the logical level, enabling you to replicate specific tables or entire databases across PostgreSQL instances. Unlike physical replication, which replicates the entire database cluster, logical replication allows for more granular control and is particularly useful for scenarios such as data migration, high availability, or multi-master replication setups.

Prerequisites

• Two PostgreSQL instances running on different servers or the same server for simplicity.
• Basic familiarity with SQL commands and PostgreSQL configuration.

Setup Overview

In this example, we’ll configure logical replication between two PostgreSQL databases: db1 (the primary database) and db2 (the subscriber database). Our goal is to replicate a simple table from db1 to db2.

1. Preparing the Primary Database (db1)

First, we need to set up the primary database to publish changes to a table. Follow these steps:

Create the Table and Insert Initial Data

Connect to db1 and execute the following commands to create a table and insert some initial data:

CREATE TABLE table1 (ad VARCHAR(15),soyad VARCHAR(15) );

INSERT INTO table1 (ad, soyad) VALUES ('Kemal', 'oz');

Create a Publication

A publication is a named collection of changes (inserts, updates, and deletes) that you want to replicate. Create a publication for all tables:

CREATE PUBLICATION alltables12 FOR ALL TABLES;

2. Preparing the Subscriber Database (db2)

Next, configure the subscriber database to receive data from the publication created on db1.

Create the Table

Ensure that db2 has the same table structure as db1:

CREATE TABLE table1 (ad VARCHAR(15),soyad VARCHAR(15) );

Create a Subscription

A subscription connects to a publication and applies changes from it. Execute the following command to create a subscription in db2:

CREATE SUBSCRIPTION mysub1 CONNECTION 'host=localhost port=5432 user=postgres dbname=test9' PUBLICATION alltables;

Replace the connection parameters (host, port, user, and dbname) with those appropriate for your setup.

3. Testing the Replication

To verify that replication is working, insert new data into the table on db1 and check if it appears in db2.

Insert Data into db1

Execute the following command on db1:

INSERT INTO table1 (ad, soyad) VALUES ('alı', 'oz');

Verify Data in db2

Connect to db2 and check the table contents:

SELECT * FROM table1;

You should see both the initial data and the new data inserted into db1:

ad   | soyad
-------+-------
Kemal | oz
alı   | oz

Conclusion

Logical replication in PostgreSQL provides a flexible and powerful method to synchronize data between databases. By following these steps, you have set up a basic replication scenario between two PostgreSQL instances. You can extend this setup to more complex scenarios, such as replicating specific subsets of data or implementing multi-master replication.
