Automating Postgres Maintenance with Ansible

In database management, routine maintenance is crucial to ensure optimal performance and reliability. One common issue that arises is table…

Automating Postgres Maintenance with Ansible

In database management, routine maintenance is crucial to ensure optimal performance and reliability. One common issue that arises is table bloat, which can significantly impact query performance and overall database efficiency. In this article, we’ll explore how to automate the process of checking for table bloat in PostgreSQL and running pg_repack to reclaim space using Ansible.

Why Manage Table Bloat?

Table bloat occurs when the physical size of a table increases beyond what is necessary for storing the actual data. This often results from frequent updates and deletions, leading to dead tuples that consume space but are not returned in query results. If left unchecked, bloat can lead to increased disk usage and slower query performance.

The Role of pg_repack

pg_repack is a tool that can help combat table bloat by reorganizing tables and reclaiming wasted space without requiring downtime. It essentially rebuilds tables in the background, allowing you to maintain performance while cleaning up bloat.

Overview of Our Automation Strategy

We will create a shell script to check for table bloat across all tables in a specified PostgreSQL database. If bloat is found to exceed a defined threshold, the script will automatically run pg_repack on the affected tables. We'll then write an Ansible playbook to schedule this script for execution.

What is Ansible?

Ansible is an open-source automation tool used for configuration management, application deployment, and task automation. It allows system administrators to manage servers and applications through simple, declarative configuration files known as playbooks. Ansible can greatly simplify routine tasks, making it easier to maintain and deploy infrastructure.

Installing Ansible

To get started with Ansible, you need to install it on your system. If you are using a Red Hat-based distribution like CentOS or Fedora, you can easily install Ansible using the following command:

sudo dnf install ansible

After installation, you can verify that Ansible is working by checking its version:

ansible --version

Step 1: Create the Bloat Check and Repack Script

Create a shell script named check_bloat_and_repack.sh. This script will connect to the PostgreSQL database, assess table bloat, and run pg_repack when necessary.

#!/bin/bash

# IP and Port
IP="10.**.**.**"
PORT="1907"

# Bloat percentage threshold
BLOAT_THRESHOLD=20.0

# .pgpass file check
PGPASS_FILE="/var/lib/pgsql/.pgpass"

if [ ! -f "$PGPASS_FILE" ]; then
  echo "$PATRONI_IP:$PATRONI_PORT:*:postgres:password" > "$PGPASS_FILE"
  chmod 600 "$PGPASS_FILE"
fi

# Database to check
db="your_database_name"

# Check for bloat
bloat_info=$(psql -h $IP -p $PORT -U postgres -d $db -t -c "
SELECT schemaname, tblname,
  CASE WHEN tblpages > 0 AND tblpages - est_tblpages_ff > 0
    THEN 100 * (tblpages - est_tblpages_ff) / tblpages::float
    ELSE 0
  END AS bloat_pct
FROM (
  SELECT ceil(reltuples / ((bs - page_hdr) / tpl_size)) + ceil(toasttuples / 4) AS est_tblpages_ff,
         tblpages, bs, tblid, schemaname, tblname, is_na
  FROM (
    SELECT (4 + tpl_hdr_size + tpl_data_size + (2 * ma)
            - CASE WHEN tpl_hdr_size % ma = 0 THEN ma ELSE tpl_hdr_size % ma END
            - CASE WHEN ceil(tpl_data_size)::int % ma = 0 THEN ma ELSE ceil(tpl_data_size)::int % ma END
           ) AS tpl_size,
           (heappages + toastpages) AS tblpages,
           heappages, toastpages, reltuples, toasttuples, bs, page_hdr, tblid, schemaname, tblname, fillfactor, is_na
    FROM (
      SELECT tbl.oid AS tblid, ns.nspname AS schemaname, tbl.relname AS tblname, tbl.reltuples,
             tbl.relpages AS heappages, COALESCE(toast.relpages, 0) AS toastpages,
             COALESCE(toast.reltuples, 0) AS toasttuples,
             COALESCE(substring(array_to_string(tbl.reloptions, ' ') FROM 'fillfactor=([0-9]+)')::smallint, 100) AS fillfactor,
             current_setting('block_size')::numeric AS bs,
             CASE WHEN version() ~ 'mingw32' OR version() ~ '64-bit|x86_64|ppc64|ia64|amd64' THEN 8 ELSE 4 END AS ma,
             24 AS page_hdr,
             23 + CASE WHEN MAX(COALESCE(s.null_frac, 0)) > 0 THEN (7 + COUNT(s.attname)) / 8 ELSE 0::int END
               + CASE WHEN BOOL_OR(att.attname = 'oid' AND att.attnum < 0) THEN 4 ELSE 0 END AS tpl_hdr_size,
             SUM((1 - COALESCE(s.null_frac, 0)) * COALESCE(s.avg_width, 0)) AS tpl_data_size,
             BOOL_OR(att.atttypid = 'pg_catalog.name'::regtype) OR SUM(CASE WHEN att.attnum > 0 THEN 1 ELSE 0 END) <> COUNT(s.attname) AS is_na
      FROM pg_attribute AS att
      JOIN pg_class AS tbl ON att.attrelid = tbl.oid
      JOIN pg_namespace AS ns ON ns.oid = tbl.relnamespace
      LEFT JOIN pg_stats AS s ON s.schemaname = ns.nspname AND s.tablename = tbl.relname AND s.inherited = false AND s.attname = att.attname
      LEFT JOIN pg_class AS toast ON tbl.reltoastrelid = toast.oid
      WHERE NOT att.attisdropped
      AND tbl.relkind IN ('r', 'm')
      GROUP BY 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
    ) AS s
  ) AS s2
) AS s3
WHERE schemaname NOT IN ('pg_catalog', 'information_schema');
")

# Check bloat percentage and run pg_repack on exceeding tables
while IFS="|" read -r schemaname tblname bloat_pct; do
    bloat_pct=$(echo $bloat_pct | xargs) # Remove leading/trailing whitespace
    if (( $(echo "$bloat_pct > $BLOAT_THRESHOLD" | bc -l) )); then
        echo "Significant bloat found in database $db, table $schemaname.$tblname (bloat_pct: $bloat_pct). Running pg_repack..."
        /usr/pgsql-13/bin/pg_repack -h $PATRONI_IP -p $PATRONI_PORT -U postgres -d $db -t "$schemaname.$tblname"
    else
        echo "No significant bloat found in database $db, table $schemaname.$tblname (bloat_pct: $bloat_pct)."
    fi
done <<< "$bloat_info"

Step 2: Create the Ansible Playbook

Now, we will create an Ansible playbook named pg_repack_bloat_check.yml to run our script on specified database servers.

---
- name: Check PostgreSQL Table Bloat and Run pg_repack
  hosts: db_servers
  become: yes
  become_user: postgres
  vars:
    ip: "10.**.**.**"
    port: "1907"
    bloat_threshold: 20.0
    script_file: "/var/lib/pgsql/check_bloat_and_repack.sh"  # Path to your shell script

  tasks:
    - name: Ensure .pgpass file exists
      copy:
        content: "{{ ip }}:{{ port }}:*:postgres:password"
        dest: "/var/lib/pgsql/.pgpass"
        mode: '0600'
      when: not ansible_env.HOME == "/var/lib/pgsql" or not lookup('file', '/var/lib/pgsql/.pgpass')

    - name: Execute the bloat check and pg_repack script
      command: bash {{ script_file }}
      register: script_output
      ignore_errors: yes

    - name: Display script output
      debug:
        var: script_output.stdout_lines

Step 3: Running the Playbook

To execute the playbook, use the following command:

ansible-playbook -i inventory.ini pg_repack_bloat_check.yml

# Schedule with crontab
0 2 * * * /usr/bin/ansible-playbook -i /var/lib/pgsl/inventory.ini /var/lib/pgsql/pg_repack_bloat_check.yml >> /var/log/ansible_pg_repack.log 2>&1

Conclusion

By following this guide, you can automate the process of checking for table bloat in your PostgreSQL databases and running pg_repack as needed. This not only improves performance but also ensures your databases remain efficient and responsive. With Ansible, you can further extend this automation by scheduling the playbook execution using cron jobs or other scheduling mechanisms, ensuring regular maintenance without manual intervention.
